H2G Using The Layout Editor of SAP Web IDE

SAP Web IDE
How-To Guide
Provided by Customer Experience Group
H2G Using the Layout Editor of SAP Web IDE
Applicable Releases:
SAP Web IDE 1.4
Version 1.0 - October 2014
H2G Create a new SAP Web IDE plugin of SAP Web IDE
Document History
Document Version
Authored By
Description
1.0
Customer Experience
Group
First release of this guide
2.0
Customer Experience
Group
Adapted to SAP Web IDE version 1.5
TABLE OF CONTENTS
1.
Business Scenario ................................................................................................................................. 4
2.
Background Information ...................................................................................................................... 4
3.
Prerequisites ........................................................................................................................................ 4
4.
Step-by-Step Procedure ....................................................................................................................... 4

4.1 General Usage of the Layout Editor ................................................................................................ 5
4.2 Create a new Project ...................................................................................................................... 6
4.3 Introduction to the Layout Editor Using the Icon Tab Bar container. ............................................ 8
4.4 Create a List View with Data Binding .............................................................................................14
4.5 Create a Form View using the HBox and VBox Container ...............................................................20
4.6 Create a View displaying a Travel Agency using the Grid Layout with Data Binding .......................26
1.
BUSINESS SCENARIO
SAP Web IDE is a next-generation cloud-based meeting space where multiple project stakeholders can work
together from a common web interface, connecting to the same shared repository with virtually no setup
required. It includes multiple interactive features that allow you to collaborate with your colleagues and
accelerate the development of your HTML5/UI5 applications.
2.
BACKGROUND INFORMATION
In this How-To Guide we will see how to use the SAP Web IDE Layout Editor for creating application with
WYSIWG functionality. This guide only shows the usage of different Layout Controls. We dont create a
running application.
3.
PREREQUISITES
As a prerequisite you need to have your installation of SAP Web IDE up and running. For the Data Mapping
you need the metadata.xml file of the RTMSAMPLEFLIGHT oData service.
4.
STEP-BY-STEP PROCEDURE
This is the sequence of steps:

1) General Usage of the Layout Editior
2) Create a new Project
3) Create a Main View with the Icon Tab Bar
4) Create a List View with Data Binding
5) Create a Form View using the HBox and VBox Container
6) Create a View displaying a Travel Agency using the Grid Layout with Data Binding
4.1 General Usage of the Layout Editor

The Layout Editor can be used for SAPUI5 Views using the Mobile Libraries ( sap.m.*) and the XML View
Layout.
Some Limitations:
The Layout View does not support comments you will get the following warning:
You have to use the sap.m.Page control on the root level
4.2
Create a new Project
The first thing you need to do is to create a new Project

1. Open SAP Web IDE
2. Select the Local folder. In the menu select File New Project or select Ctrl+Alt+Shift+O.
3. Enter the name of the project (i.e. layoutsample) and click on Next
4. Select the SAPUI5 Mobile App Project template and click next
5. Create an initial view (i.e. main) and click next and finish the project wizard
Actually the layout editor only support the mobile application type and the XML view type
6. Project folder
4.3
Introduction to the Layout Editor Using the Icon Tab Bar container.
In this step we will adding components to the Main view and set the properties
1. Open the view folder in your project and right-click on the Main.view.xml file. Choose Open With
Layout Editor
The Layout Editor is starting and displays an empty page with a title bar.
The Layout Editor has 4 different panels:
1) The View Pane

This is the workspace where you can design your view by placing controls.
2) The Control Pane
It shows the palette of the available controls. It could be hidden by pressing the << icon. To find a
control you can use the search field on top of the pane.
3) The Properties and Data Pane

Here you can change the properties of a selected control. For controls that allow data binding you
can choose the appropriate oData service and field. To use data binding an oData metadata.xml file
must attached in the model folder of the project.
4) The Outline Pane shows the control hierarchy of the view. It can be open and closed by selecting the
Outline icon on the right side of the Web IDE page.
2. Open the Container Folder in the Control Pane and select the Icon Tab Bar control. Drag it on the view
3. Change the properties of a control.

Select the Open Tab Filter:
10
Open the Property pane and change the following properties

Property
Icon Color
Count
Key
Icon
Text
Value
default
20
todo
sap-icon://to-be-reviewed
ToDo
And you get the following layout:
11
4. Add an additional Icon Tab Filter to the Icon Tab Bar

Select the Icon Tab Filter in the Control pane and drop it to view. You have to press the Ctrl-key to
drag it inside the Tab Bar header.
5. Select the Main.view.xml and open it with the Text Editor:
Select the following coding

<content>
<Text text="Special content for this tab goes here ..." maxLines="0"></Text>
</content>
and copy it between the last <IconTabFilter .></IconTabFilter> tags
12
Press Save.
6. Go back to the Layout Editor and select the Open Icon Tab.
7. You can now add special content to this Tab. In the Control pane search for Calendar and drag the
control into Open Tab. You have to press the Ctrl-key to place the control inside the Tab.
8. Select
and press delete.
13
4.4
Create a List View with Data Binding
...
1. Create a new View. Right-click on the view folder in the project tree. Select
2. Select the SAPUI5 View template and click next.
3. In the Template Customization select Mobile and XML as Application and View Type. Name the View
TravelAgencyList. Click next and finish.
4. Add the oData model to the project.

Right-click on the layoutsample folder . Choose New Folder.
Name the folder model
For the exercise we use the metadata.xml from the RMTSAMPLEFLIGHT oData service of the default
Netweaver Gateway installation.
Two options:
a. Import the oData metadata.xml file.
14
If you have already the metadata.xml file of the RMTSAMPLEFLIGHT service right-click on the
model folder. Choose Import File.
b. Create the metadata.xml.

Right-click on the model folder. Choose New File. Name the file metadata.xml.
Open the file in the text editor. Copy the content of the Appendix A into it and save the file. The
content spans over 4 pages. To avoid copying the page header do it page by page.
..
4. Open the TravelAgencyList View with the Layout Editor Open the List Control folder and drag the
List into the View
15
16
5. Open the Outline pane
6. Navigate to the sap.m.List items folder, select the sap.m.StandardListItems and remove them by
pressing the delete key.
You will get an empty List
7. Drag an ObjectListItem into the List you have to press the Ctrl-Key while dragging, otherwise the
ObjectListItem will be placed outside of the List control.
17
8. Binding the oData model to the sap.m.List

In the Outline pane select the sap.m.List item open the Data pane and bind the TravelAgency_DQ to
it.
9. Binding the oData model to the ObjectListItem

Open the Outline pane. In the Outline pane move to content- sap.m.List items
sap.m.ObjectListItem- properties
Select the title property. In the Property pane the fields of the Travelagencies_DQ collection are
displayed. Choose the NAME field.
18
Bind the number property to the agencynum field
Bind the intro property to the URL field
Open the Properties pane and clear the entry for the Number Unit property
19
You will get the following view:
4.5
Create a Form View using the HBox and VBox Container
In this chapter we are using the HBox and VBox Container to create a form view with input controls.
1.
Create a new SAPUI5View Component like in 4.4
2.
Open the view with the Layout Editor.
3.
In the Control Palette open the Container folder and drag the VBox control to the view.
20
4.
Into the VBox control drag 2 HBox controls (keep pressing the Ctrl-Key while dragging). You can check
in the Outline pane if the HBox are placed in the correct hierarchy.
5.
Now you can add multiple Display controls inside the HBoxes. Select the appropriate HBox before
inserting a Display control and press the Ctrl-Key while dragging. In the Outline Pane you can check for
the correct Control hierarchy.
21
6.
Add an Image control to the first HBox. Select the Image Control. You can change the displayed image
by changing the image URL in the Src property:
7.
Add a Label and an Input control to the second HBox
8.
Add three additional HBoxes to the VBox. If you have problems placing the controls release the Ctrl-Key
and press it again you will see that the highlighting of the controls is changing.
22
9.
Add a Date Input Control

Add a Label and an Input control to the third HBox control. Select the input control and open the
Properties pane. In the first Data section change the Type to Date
10. Add a Label and a Select Control to the fourth HBox

11. Add 2 Buttons to the fifth HBox
12. Format your controls by changing the properties:
Control
Sap.m.Page
Property
Title: Registration Form
Width: 300px
Src:
23
hIYGyceFxkjHBISHy8gIycpLC8sFSAxNTAqNSYrLCkBCQoKDgwOFQ8PFTUkHCQsLDIpKSozNSktLCo0LCkqNSwqLiwpKiopKSkvLCopN
S8qKSkqKSksKSspKSkpLCkpNf/AABEIAJIBWAMBIgACEQEDEQH/xAAbAAACAgMBAAAAAAAAAAAAAAAAAQIDBQYHBP/EAEQQAAI
BAgIFBwkGBQEJAAAAAAABAgMRBBIFExVTkgYhMUFRUtEHIjJhcXKRstIUFnOBk7FCYoKhwSQjMzRDVHSis+H/xAAbAQEBAAMBAQE
AAAAAAAAAAAAAAQQFBgIHA//EADgRAAECAwUFCAECBQUAAAAAAAABAgMEEQUVUZHREjFBUvAWITJTYXGBoRMGVCI0NXKxF
CNCYsH/2gAMAwEAAhEDEQA/AM+kTUQii2MT5WqnXVIqJLITSJWISpXkHkLLDsQVK8gZCyw7EoKleQeQssOwoKlWQeQssOxKFqVZB5
Cyw7CgqVZB5SywWFBUryBlLLBYUJUqyBkLbBYULUpyBkLbBYUFSnIGQtsFhQVKcgshdYVi0JUqyCyFtgsWgqU5BZC6wrAVKcgshdYVii
pVkFkLbBYpKlOQWQusJoCpTkDIW2CxRUpyCyF1hWKKlDgQcT0OJCSKiipXQXnw9+HzICVJefD34/MgNpJ+FTHj70LoIuiVQLkafiZKkkNC
RIpBhYBkAWGkCQ0gBWGA7EAAkAwAsFgGCCGFgACwDsIAQWHYABWE0MAUQhhYAjYGhg0ARsKxJoRQKwrDsABGwrErCKQjYLDE
wBWFYkIAjYViQigiDQxMoItEZImyLAK6a8+Hvx/dAOn6cPfj8yA2kn4VMeNvQtgWoqgWo1BlKTQxIaBCQxDQAIYhkAxiAAYAAAHnxuK1UV
JK95JWbt1PwPQY7TrtSX4kf2ZsrJgsjzkGHESrVVKoa+0or4UrFexaKidyle233FxMNtvuLifgYVTPdS0NiprNHC13F9D1U7P+x9TX9PWW3fB
TNdT5222bSd4Yqr8Joezbj7i4n4Btt9xcT8DH4jRtekr1MPVprtlSml8bHl1gT9PWYu6Cma6kW2bRb3LFXJNDNbbfcXExbbfcXEzEU7yajFOUn
zKMU22/YX7Pr7it+lU8Av6esxN8FM11Kls2iu6KuSaGQ22+4uJhtt9xcTMRUvFuMk4yXTGSaa/JkqNKdS6pwnUa6VCMpW+A7O2Zv/Ama6k
vq0a0/KuSaGV20+4uJhtp9xfFmP2fX3Fb9Kp4EamFqx55UakV/NTmv8E7P2X5KZrqer5tLzVyTQyO2n3F8WG2X3F8WYfWBrD12ds3yEzdq
eL8tDzvpNDMbZfcXxYbYfcXxZh9YGsHZ2zfITN2ovy0PO+k0Mvth9xfFnswteVRZnFRj1c7uzG6NwGe1Sa8zqXe/wDhmbHD2+tmwFWXlISbf
/J1VWnonfSuOG7fu6+xUn4yJHmYq7PBtESvqvduwx9t6EMRyZ04CYyLBAExiYKJgwYmUgMiSYmARZFkmRZQQp+nD34/MgCn6cPfj8yA2
cl4VMeNvQtgWopgXRNSZKk0NEUSQBJAIYAxiAgGMQwBgIYAGM0/FulCMVeUqsIpLpbaasZM8uMrRpzwk5+hHGUHK/Ra75zbWKtJ+Av/
AGQ11qJtSkVPQ2vk5yXpYKnGTiqmJaTnVavZ92PYv3MtXxdOlbWVIU79GecY3+LLjSuVvIiriq08Vh6ilOSjmo1XboVvNl1dHQ/ifSGUjP8A91
1PU5l6LLwqQWVpw63m40q0Zq8JRnHtjJSX9jnnlCxNBVoUaVKEa0VmrVYxyvnXNDm6e3n9RrlfB4vR880oVsLJOyqRvGL/AK1zM8NfFSqT
lUqScpzk5Tk+lt9ZtJeUSG/bR1UNPNzqxYf41ZRTcvJzo7WYipiWvNoRyx/Fn4RvxI6MYTkdov7LgaMZK1SotdU7c0+e35LKvyMhtKH2n7J/zd
Rr/wCjPl/c1sy9YsVypuT/AAbaThJAgtau9f8AKmjeUfR2rr0sTFebXjkn+JDof5x+Un5MpXq4r8On8zNn5YaM+04GtBK86a11P34c9vzWZfmar
5LpXrYr8Ol8zMtsTblHJxTUwHQPxzzXJuXv+lOht253zJChUjL0ZKXsaZ49N/8AB4r/ALav/wCuRxfBYqpSqQnQlKFVNZHDmbl1Lm6b9hjS8r
+ZqrtUoZs1Of6dzU2a1OxaX5N4fFwanTjGo15taCUakX236/YzlGk8FPC16mHqenSla66JLpUvY00/zO0023GLkrSsrrsdjl/lIstIK3S8PScvbeS/
wZFnxXbasVe4xLUl2KxIiJ31NczmV0VotztUqK0OmMX/AB+v2EdDaIz2q1V5nTCD/j9b9RsJzv6h/UX49qVlV/i3OcnD0T1xXhw792bY1h7dJi
YTu4Nx9V9PTj7b0AAfODuBCGxFKITGIEAQxAohDEUgmDAQAmQkTZCRQRp+nD34/MgCn6cPfj8yA2cl4VMeNvQsgXIpgWo1XEyVJokiK
GgQkMQEKMYhgDAQyAYCGAMw3Kl/6eP4sflkZgwnK5/6aP40Plkbew/6hA/uQ1tq/wAnF9jI8mfKNqoRw+NUpxilGGIj50lHslHr9q5/ab3o/TO
HxKvQr06vqjJZl7Y9KOa4TycV6+DpYmnUiq1WOfUVE4rI/R8/qbVnZrrMeuQ+koTWXCzUk+acKtFJevNm5j6vEgS8RVVr6KcVCmJmEiI5lU6
67zstSnGcXGUVKMlZxkk012WfSaNpbkDD7dhZ4eNsNVq/7emuikorNzeqVrW6m/XzbXoChXp4SjTxc9ZiYxesnfN1uyv1tKyv12Mga5kV0Fy7
KmzfBZHam2mHv7COWLlMtu/acy1Wv+zXvzan/d3+PnHVDz7Po5tZqaWfpz6uGb42uWBFbD2tpK1ShJiC6Js7LqUWp6DTOSWjPsmk9JUE
rQUac6f4UpOS+F7fkbmedYKKrvELmnKkqUvXFSzL4Xl8TwyJstc3FD3Eh7TmOwX/AMLa1KM4yhNZoTi4yi+hxas1/c8GC5N4TDyVSjhqUJr
oko3a9jfQX6WxEqWGxFWDtOnQrTi2rpSjBtc3tRyeXlI0g1bXQXrVGnc/aXgRIqLsLRD8JmYhQXJttqvA65jcbTw9OVatONOnBXlKTsvZ636j
mdaD0hi6mPrRcaUmlQpS6XTirJv1ddu1vqPLgaOIxrjicdVqVoLnp06j5n/Nl6EvYuczhy9sWukrtS0s6r9znJw9G+uK8Nyd5tZKTWa2Y0ZtG72t
Xj6r6YJx9gABHDnSAIYgBAAikBiBgAAgYgUBDYikEIYgBMhImyEigjT9OHvx+ZAFP04e/H5kBtJLwqY8behOBdEpgXRNTxMlSaGiKJIEGM
QEKSAQwBgIZAMBDAGYXlTUUKNKUoKpGOIpOVNtpTilJ5brqZmTA8sn/pY/jQ+WZt7D/qED+5DXWr/JxfY23RXlOwVWKVbNhJ9GWpFyp
/lOPV7UjNw5VYGSzLG4e3rrQT+DZwO4rn111mw1XuVUODZakVEoqIp2rSvlGwOHi8lX7VU/hp0OdN+ub5kvj7D0U+Xej8qzY2jmss2X PbN
bq5ug4dcLi7YVKVUXpFrWiHR+X3LeFSGHp6PxTbU5VKtShKcHGyso35unNJ/kjVPvpj7Zftta3vK/xtcwdwuZUOWhsajaV9zDizMSI5XVp7HS
eQXLiEKVenpDFNS1iqU6leU5ykpRs435+hxT/qNq+/ejv+tpf+fgcMuFzHiSEN7ldWhkwrRiw2o2iLTE7PpnlrgKmFxNOGMpynPD1oRis95SdO
SS6O1nPeTvJ/Plr115nTTpv+P+Z+r9yPJ3k7ny4iuvM6adN/x/zP1errNuOItu2myqPlJN3evidh6J64rw4d+7pbPs900rZiab3J4W4+q+npx9gEA
HAnVgIBAAIYigBAJggAAgUBDEUghDEAAmAigGQZJkWCEafpw9+P7oAp+nD34/MgNpJeFT8I29CcC1FMC1GpMlSxDIpjBCQyIwBjI3Hch
SQER3AJARAAkebSGj4YmCp1U3FSUvNeV3Sa/yz0XA9w4j4T0exaKm5UPD2NiNVr0qi8DD/dHDd2f6jD7o4buz/UZmANjfNofuHZqYd2ynkt
yMP90cN3Z/qMPujhu7P9RmYAXzaH7h2ai7ZTyW5GH+6OG7s/1GH3Rw3dn+ozMAL5tD9w7NRdsp5LcjDfdLDd2f6jJ0uSuGjJSySlld7Sm5
Rb9nWZa4iLbE+qKizDs1KlnSiLVILckGAguawzhiEFwAAVwAABXApAYgEAMQgAAQCKBsQCAAQA2UgmRYyLBRU/Th78fmQCp+nD34/
MgNpJ+FTHjb0HBl0WeaLLYyNUqGUpcmSuVKRLMQ8llwuQzBmFQWXC5DMGYhSy4XIZgzAE7juV5h5hUE7hchcMwqCy4XK8w8wBO4X
IZgzAE7iuQzBmFQTuFyFwzCoJXC5DMGYAncVyOYWYAncVyOYWYoJ3FcjmFmBCVwuRzCzAEriuRzBmKCVxEcwXAJXFcjcWYAkK4sw
sxQNkWwciuUiglTfnw9+PzIRGk/Ph78fmQzaSafwqY8behkfu9iV00Xx0/qIPRFddNNr+qHidFdNHnnhE+o39wy/M7NNDW3jFwTr5NDWjK27f
FHxGtGVt2+KPib0sEuwksGuwlwS3M7NNBeMXBOvk0VaLrbt8UPEa0TX3T4oeJvawsewksOuwXBLczs00F4xcE6+TQ1oevunxQ8SS0NiN0
+KHib3qV2D1S7Cdn5bmdmmgvGLgnXyaJsXEbp8VPxDYmI3T46fib5q12Bq0Oz8tzOzTQXjFwTr5NE2JiNy+On4hsTEbl8dPxN71aDVodn5
bmdmmgvGLgn3qaLsPEbl8dPxDYmI3T46fib1q0GrQ7Py3M7NNBeMXBPvU0XYmI3L46fiGxMRuXx0/E3rVoNWh2fluZ2aaC8YuCfepouxM
RuXx0/ENiYjcvjp+JvWrQatDs/Lczs00F4xcE+9TRdiYjcvjp+IbExG6fHT8TetWg1aHZ+W5nZpoLxi4J96mi7DxG5fHT8Q2HiNy+On4m9atBq0
Oz8tzOzTQXjFwTr5NE2HiNy+On4hsPEbl8dPxN71aDVodn5bmdmmgvGLgn3qaJsPE7l8dPxFsPE7l8dP6jfNWg1aHZ+W5nZpoLxi4J18mh7
CxO5fHT+oNhYncvjp/Ub5q0GrRez8tzOzTQXjFwTr5NC2Fidy+On9QbCxO5fHT+o33VoNWhcEtzOzTQXjFwTr5NB2Fidy+On9QbBxO5fHT+
o37VoNWhcEtzOzTQXjEwTr5NA2Didy+On9QthYncvjp/UdA1aDVoXBLczs00F4xME+9Tn+wsTuXx0/EjsPEbl8dPxOhatdgtUuwXBLczs00F
4xME6+Tnr0LiN0+Kn4i2PiN0+KHidC1C7BPDrsLcMvzOzTQXjEwTr5OePRFfdPih4i2VX3T4oeJ0J4WPYReDXYLhl+Z31oLxiYJ18nPXoqvu
3xQ8QWhcQ+ik+KHidAeCXYSp4VLqLcUvzO+tBeMTBOvk0KjycxWeD1LspRb8+l0X94Z0NQQH7w7Jgw0ojl+tDw6eiO3onXySAANsYIAAA
AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAB
Label 1
Input 1
Label 2
Input 2
Label 3
Select 1
Button 1
Button 2
Width: 50px
Text: Name
Width: 220px
Width: 50px
Text: Date
Width: 220px
Type: Date
Width: 50px
Text: Event
Width: 220px
Width: 150px
Icon: sap-icon://accept
Text: OK
Width: 150px
Icon: sap-icon://undo
Text: Cancel
You get the following view:
24
25
4.6
Create a View displaying a Travel Agency using the Grid Layout with Data Binding
...
Here we create a View for displaying a single Data Set using the Grid Layout control.
Choose the me nu o ption File -> N ew - > Proj ect
1. Create a new View Like in 4.4 use the new component wizard and create a view named
TravelAgency with Application Type = Mobile and View Type = XML
2. Open the TravelAgency.view.xml with the Layout Editor

and drag the Grid control to the view
In the control pane open the Layout folder
3. Remove all the controls inside of the Grid control (select and press delete)
4. Open the Display folder in the control pane and drag an Object Identifier to the Grid control (press the
Ctrl-key while dragging).
26
5. Open the Outline Pane, move to the sap.ui.layout.Grid - content sap.m.ObjectIdentifier properties
subfolder. Click on the title property in the Properties pane. Open the Data folder, select the
TravelAgencies_DQ NAME field.
6. Select the text property and bind it to the URL field of the TravelAgencies_DQ
27
7. If you do not need the Badge icons you can remove them in the property pane
8. Drag an Object Attribute control to the Grid control (keep pressing the Ctrl-key while dragging).
28
9. In the Outline pane select the text property of the sap.m.ObjectAttribute and bind the
TravelAgencies_DQ COUNTRY field to it.
10. Add an additional ObjectAttribute and bind it to TravelAgencies_DQ CITY

11. Bind the Title to a Data Field. In the Outline Pane move to sap.m.Page properties title. Map the title
to the TravelAgencies_DC agencynum field
29
12. You get the following result:
13. You can change the spacing between the elements in the properties of the sap.ui.layout.Grid
30
Appendix
A. metadata.xml
<?xml version="1.0" encoding="utf-8"?>
<edmx:Edmx Version="1.0"
xmlns:edmx="http://schemas.microsoft.com/ado/2007/06/edmx"
xmlns:gp="http://www.sap.com/Protocols/SAPData/GenericPlayer"
xmlns:m="http://schemas.microsoft.com/ado/2007/08/dataservices/metadata"
xmlns:sap="http://www.sap.com/Protocols/SAPData"
xmlns:ux="http://www.sap.com/Protocols/OData4SAP/UX">
<edmx:DataServices m:DataServiceVersion="2.0">
<Schema Namespace="RMTSAMPLEFLIGHT" xml:lang="en" sap:schema-version="0000"
xmlns="http://schemas.microsoft.com/ado/2008/09/edm">
<EntityType Name="Subscription" sap:semantics="subscriptions" sap:content-version="1">
<Key>
<PropertyRef Name="ID"/>
</Key>
<Property Name="ID" Type="Edm.String" Nullable="false" MaxLength="32" sap:label="Sub. ID" sap:creatable="false" sap:updatable="false" sap:filterable="false"/>
<Property Name="user" Type="Edm.String" MaxLength="12" m:FC_TargetPath="SyndicationAuthorName" m:FC_KeepInContent="false" sap:label="User Name" sap:creatable="false" sap:filterable="false"/>
<Property Name="updated" Type="Edm.DateTime" Precision="0" m:FC_TargetPath="SyndicationUpdated" m:FC_KeepInContent="false" sap:label="Time Stamp" sap:creatable="false" sap:filterable="false"/>
<Property Name="title" Type="Edm.String" MaxLength="255" m:FC_TargetPath="SyndicationTitle" m:FC_KeepInContent="false" sap:label="Title" sap:filterable="false"/>
<Property Name="deliveryAddress" Type="Edm.String" sap:label="Delivery Address" sap:filterable="false"/>
<Property Name="persistNotifications" Type="Edm.Boolean" sap:label="Persist Notification" sap:filterable="false"/>
<Property Name="collection" Type="Edm.String" MaxLength="40" sap:label="Collection" sap:filterable="false"/>
<Property Name="filter" Type="Edm.String" sap:label="Filter" sap:filterable="false"/>
<Property Name="select" Type="Edm.String" MaxLength="255" sap:label="Select" sap:filterable="false"/>
<Property Name="changeType" Type="Edm.String" MaxLength="30" sap:label="Change Type"/>
</EntityType>
<EntityType Name="Notification" sap:semantics="notifications" sap:content-version="1">
<Key>
<PropertyRef Name="ID"/>
</Key>
<Property Name="ID" Type="Edm.String" Nullable="false" MaxLength="32" sap:label="Notification ID"/>
<Property Name="collection" Type="Edm.String" MaxLength="40" sap:label="Collection"/>
<Property Name="title" Type="Edm.String" m:FC_TargetPath="SyndicationTitle" m:FC_KeepInContent="false" sap:label="Notif. Text"/>
<Property Name="updated" Type="Edm.DateTime" Precision="0" m:FC_TargetPath="SyndicationUpdated" m:FC_KeepInContent="false" sap:label="Time Stamp"/>
<Property Name="changeType" Type="Edm.String" MaxLength="30" sap:label="Change Type"/>
<Property Name="entriesOfInterest" Type="Edm.Int32" sap:label="No. of Entries"/>
<Property Name="recipient" Type="Edm.String" MaxLength="112" sap:label="Recipient" sap:creatable="false" sap:updatable="false"/>
</EntityType>
<EntityType Name="Flight" sap:content-version="1">
<Key>
<PropertyRef Name="carrid"/>
<PropertyRef Name="connid"/>
<PropertyRef Name="fldate"/>
</Key>
<Property Name="flightDetails" Type="RMTSAMPLEFLIGHT.FlightDetails" Nullable="false"/>
<Property Name="carrid" Type="Edm.String" Nullable="false" MaxLength="3" sap:label="Airline"/>
<Property Name="connid" Type="Edm.String" Nullable="false" MaxLength="4" sap:label="Flight Number"/>
<Property Name="fldate" Type="Edm.DateTime" Nullable="false" Precision="0" sap:label="Date"/>
<Property Name="PRICE" Type="Edm.Decimal" Precision="15" Scale="2" sap:unit="CURRENCY" sap:label="Airfare"/>
<Property Name="CURRENCY" Type="Edm.String" MaxLength="5" sap:label="Airline Currency" sap:sortable="false" sap:semantics="currency-code"/>
<Property Name="PLANETYPE" Type="Edm.String" MaxLength="10" sap:label="Type of the plane"/>
<Property Name="SEATSMAX" Type="Edm.Int32" sap:label="Max. capacity econ."/>
<Property Name="SEATSOCC" Type="Edm.Int32" sap:label="Occupied econ."/>
<Property Name="PAYMENTSUM" Type="Edm.Decimal" Precision="17" Scale="2" sap:label="Total"/>
<Property Name="SEATSMAX_B" Type="Edm.Int32" sap:label="Max. capacity bus."/>
<Property Name="SEATSOCC_B" Type="Edm.Int32" sap:label="Occupied bus."/>
<Property Name="SEATSMAX_F" Type="Edm.Int32" sap:label="Max. capacity 1st"/>
<Property Name="SEATSOCC_F" Type="Edm.Int32" sap:label="Occupied 1st"/>
<NavigationProperty Name="flightbooking" Relationship="RMTSAMPLEFLIGHT.BookingFlight" FromRole="FromRole_BookingFlight" ToRole="ToRole_BookingFlight"/>
<NavigationProperty Name="flightBookings" Relationship="RMTSAMPLEFLIGHT.FlightBookings" FromRole="FromRole_FlightBookings" ToRole="ToRole_FlightBo okings"/>
<NavigationProperty Name="FlightCarrier" Relationship="RMTSAMPLEFLIGHT.CarrierToFlight" FromRole="ToRole_CarrierToFlight" ToRole="FromRole_CarrierToFlight"/>
<NavigationProperty Name="FlightCarrier_FW" Relationship="RMTSAMPLEFLIGHT.CarrierToFlight" FromRole="ToRole_CarrierToFlight" ToRole="FromRole_CarrierToFlight"/>
</EntityType>
<EntityType Name="Flight_DQ" sap:content-version="1">
<Key>
</Key>
<Property Name="PRICE" Type="Edm.Decimal" Precision="15" Scale="2" sap:unit="CURRENCY" sap:label="Airfare"/>
<Property Name="CURRENCY" Type="Edm.String" MaxLength="5" sap:label="Airline Currency" sap:sortable="false" sap:semantics="currency-code"/>
<Property Name="PLANETYPE" Type="Edm.String" MaxLength="10" sap:label="Type of the plane"/>
<Property Name="SEATSMAX" Type="Edm.Int32" sap:label="Max. capacity econ."/>
<Property Name="SEATSOCC" Type="Edm.Int32" sap:label="Occupied econ."/>
<Property Name="PAYMENTSUM" Type="Edm.Decimal" Precision="17" Scale="2" sap:label="Total"/>
<Property Name="SEATSMAX_B" Type="Edm.Int32" sap:label="Max. capacity bus."/>
<Property Name="SEATSOCC_B" Type="Edm.Int32" sap:label="Occupied bus."/>
<Property Name="SEATSMAX_F" Type="Edm.Int32" sap:label="Max. capacity 1st"/>
<Property Name="SEATSOCC_F" Type="Edm.Int32" sap:label="Occupied 1st"/>
</EntityType>
<EntityType Name="Booking" sap:label="Flight Booking" sap:semantics="FLIGHT_BOOKING" sap:content-version="1">
31
<Key>
<PropertyRef Name="bookid"/>
</Key>
<Property Name="bookid" Type="Edm.String" Nullable="false" MaxLength="8" sap:label="Booking number"/>
<Property Name="CUSTOMID" Type="Edm.String" MaxLength="8" sap:label="Customer Number"/>
<Property Name="CUSTTYPE" Type="Edm.String" MaxLength="1" sap:label="B/P customer"/>
<Property Name="SMOKER" Type="Edm.String" MaxLength="1" sap:label="Smoker"/>
<Property Name="WUNIT" Type="Edm.String" MaxLength="3" sap:label="Unit of measure" sap:semantics="unit-of-measure"/>
<Property Name="LUGGWEIGHT" Type="Edm.Decimal" Precision="9" Scale="9" sap:unit="WUNIT" sap:label="Luggage Weight"/>
<Property Name="INVOICE" Type="Edm.String" MaxLength="1" sap:label="Invoice pty."/>
<Property Name="CLASS" Type="Edm.String" MaxLength="1" sap:label="Class"/>
<Property Name="FORCURAM" Type="Edm.Decimal" Precision="15" Scale="14" sap:unit="FORCURKEY" sap:label="Amount"/>
<Property Name="FORCURKEY" Type="Edm.String" MaxLength="5" sap:label="Paymnt currency" sap:semantics="currency -code"/>
<Property Name="LOCCURAM" Type="Edm.Decimal" Precision="15" Scale="14" sap:unit="LOCCURKEY" sap:label="Amount"/>
<Property Name="LOCCURKEY" Type="Edm.String" MaxLength="5" sap:label="Airline Currency" sap:semantics="currency-code"/>
<Property Name="ORDER_DATE" Type="Edm.DateTime" Precision="0" ConcurrencyMode="Fixed" sap:label="Booking date" sap:updatable="false"/>
<Property Name="COUNTER" Type="Edm.String" MaxLength="8" sap:label="Sales office" sap:updatable="false"/>
<Property Name="AGENCYNUM" Type="Edm.String" MaxLength="8" sap:label="Agency No." sap:updatable="false"/>
<Property Name="CANCELLED" Type="Edm.String" MaxLength="1" sap:label="Cancelation flag" sap:updatable="false"/>
<Property Name="RESERVED" Type="Edm.String" MaxLength="1" sap:label="Reserved" sap:updatable="false"/>
<Property Name="PASSNAME" Type="Edm.String" MaxLength="25" sap:label="Passenger Name"/>
<Property Name="PASSFORM" Type="Edm.String" MaxLength="15" sap:label="Title"/>
<Property Name="PASSBIRTH" Type="Edm.DateTime" Precision="0" sap:label="DOB of Passeng."/>
<NavigationProperty Name="bookedFlight" Relationship="RMTSAMPLEFLIGHT.BookingFlight" FromRole="ToRole_BookingFlight" ToRole="FromRole_BookingFlight" sap:label="Flight bookings" gp:display-order="0111"/>
<NavigationProperty Name="bookedCarrier" Relationship="RMTSAMPLEFLIGHT.BookingCarrier" FromRole="ToRole_BookingCarrier" ToRole="FromRole_BookingCarrier" sap:label="Type of the plane" gp:display-order="0111"/>
</EntityType>
<EntityType Name="Carrier" m:HasStream="true" sap:content-version="1">
<Key>
</Key>
<Property Name="CARRNAME" Type="Edm.String" MaxLength="20" sap:label="Airline"/>
<Property Name="CURRCODE" Type="Edm.String" MaxLength="5" sap:label="Airline Currency" sap:semantics="currency-code"/>
<Property Name="URL" Type="Edm.String" MaxLength="255" sap:label="URL"/>
<Property Name="mimeType" Type="Edm.String" MaxLength="128" sap:label="MIME Type" sap:filterable="false"/>
<NavigationProperty Name="carrierFlights" Relationship="RMTSAMPLEFLIGHT.CarrierToFlight" FromRole="FromRole_CarrierToFlight" ToRole="ToRole_CarrierToFlight"/>
<NavigationProperty Name="carrierFlights_FW" Relationship="RMTSAMPLEFLIGHT.CarrierToFlight" FromRole="FromRole_CarrierToFlight" ToRole="ToRole_CarrierToFlight"/>
</EntityType>
<EntityType Name="Travelagency" ux:thing-name="travel agency" sap:content-version="1">
<Key>
<PropertyRef Name="agencynum"/>
</Key>
<Property Name="agencynum" Type="Edm.String" Nullable="false" MaxLength="8" sap:label="Agency No."/>
<Property Name="NAME" Type="Edm.String" MaxLength="25" sap:label="Travel agency name"/>
<Property Name="STREET" Type="Edm.String" MaxLength="30" sap:label="Street"/>
<Property Name="POSTBOX" Type="Edm.String" MaxLength="10" sap:label="PO Box"/>
<Property Name="POSTCODE" Type="Edm.String" MaxLength="10" sap:label="Postal Code"/>
<Property Name="CITY" Type="Edm.String" MaxLength="25" sap:label="City"/>
<Property Name="COUNTRY" Type="Edm.String" MaxLength="3" sap:label="Country"/>
<Property Name="REGION" Type="Edm.String" MaxLength="3" sap:label="Region"/>
<Property Name="TELEPHONE" Type="Edm.String" MaxLength="30" sap:label="Tel."/>
<Property Name="URL" Type="Edm.String" MaxLength="255" sap:label="Travel agency URL"/>
<Property Name="LANGU" Type="Edm.String" MaxLength="2" sap:label="Language"/>
<Property Name="CURRENCY" Type="Edm.String" MaxLength="5" sap:label="Trav.Agency.Curr" sap:semantics="currency-code"/>
<Property Name="mimeType" Type="Edm.String" MaxLength="128" sap:label="MIME Type"/>
</EntityType>
<EntityType Name="Travelagency_DQ" ux:thing-name="travel agency" sap:content-version="1">
<Key>
<PropertyRef Name="agencynum"/>
</Key>
<Property Name="agencynum" Type="Edm.String" Nullable="false" MaxLength="8" sap:label="Agency No."/>
<Property Name="NAME" Type="Edm.String" MaxLength="25" sap:label="Travel agency name"/>
<Property Name="STREET" Type="Edm.String" MaxLength="30" sap:label="Street"/>
<Property Name="POSTBOX" Type="Edm.String" MaxLength="10" sap:label="PO Box"/>
<Property Name="POSTCODE" Type="Edm.String" MaxLength="10" sap:label="Postal Code"/>
<Property Name="CITY" Type="Edm.String" MaxLength="25" sap:label="City"/>
<Property Name="COUNTRY" Type="Edm.String" MaxLength="3" sap:label="Country"/>
<Property Name="REGION" Type="Edm.String" MaxLength="3" sap:label="Region"/>
<Property Name="TELEPHONE" Type="Edm.String" MaxLength="30" sap:label="Tel."/>
<Property Name="URL" Type="Edm.String" MaxLength="255" sap:label="Travel agency URL"/>
<Property Name="LANGU" Type="Edm.String" MaxLength="2" sap:label="Language"/>
<Property Name="CURRENCY" Type="Edm.String" MaxLength="5" sap:label="Trav.Agency.Curr" sap:semantics="currency-code"/>
<Property Name="mimeType" Type="Edm.String" MaxLength="128" sap:label="MIME Type"/>
</EntityType>
<ComplexType Name="FlightDetails" gp:display-order="0010">
<Property Name="countryFrom" Type="Edm.String" MaxLength="3" sap:label="Country"/>
<Property Name="cityFrom" Type="Edm.String" MaxLength="20" sap:label="Depart.city"/>
<Property Name="airportFrom" Type="Edm.String" MaxLength="3" sap:label="Dep. airport"/>
<Property Name="countryTo" Type="Edm.String" MaxLength="3" sap:label="Country"/>
<Property Name="cityTo" Type="Edm.String" MaxLength="20" sap:label="Arrival city"/>
<Property Name="airportTo" Type="Edm.String" MaxLength="3" sap:label="Dest. airport"/>
<Property Name="flightTime" Type="Edm.Int32" sap:label="Flight time"/>
32
<Property Name="departureTime" Type="Edm.Time" Precision="0" sap:label="Departure"/>

<Property Name="arrivalTime" Type="Edm.Time" Precision="0" sap:label="Arrival Time"/>
<Property Name="distance" Type="Edm.Decimal" Precision="9" Scale="4" sap:unit="distanceUnit" sap:label="Distance"/>
<Property Name="distanceUnit" Type="Edm.String" MaxLength="3" sap:label="Distance in" sap:semantics="unit-of-measure"/>
<Property Name="flightType" Type="Edm.String" MaxLength="1" sap:label="Charter"/>
<Property Name="period" Type="Edm.Byte" sap:label="n day(s) later"/>
</ComplexType>
<ComplexType Name="FlightAvailability">
<Property Name="ECONOMAX" Type="Edm.Int32" sap:label="Max. capacity econ."/>
<Property Name="ECONOFREE" Type="Edm.Int32" sap:label="Free seats"/>
<Property Name="BUSINMAX" Type="Edm.Int32" sap:label="Max. capacity bus."/>
<Property Name="BUSINFREE" Type="Edm.Int32" sap:label="Free seats"/>
<Property Name="FIRSTMAX" Type="Edm.Int32" sap:label="Max. capacity 1st"/>
<Property Name="FIRSTFREE" Type="Edm.Int32" sap:label="Free seats"/>
</ComplexType>
<ComplexType Name="FlightAvailability2" BaseType="RMTSAMPLEFLIGHT.FlightAvailability"/>
<Association Name="BookingCarrier" sap:content-version="1" sap:label="Booking Carrier Association">
<End Type="RMTSAMPLEFLIGHT.Carrier" Multiplicity="1" Role="FromRole_BookingCarrier"/>
<End Type="RMTSAMPLEFLIGHT.Booking" Multiplicity="1" Role="ToRole_BookingCarrier"/>
<ReferentialConstraint>
<Principal Role="FromRole_BookingCarrier">
</Principal>
<Dependent Role="ToRole_BookingCarrier">
</Dependent>
</ReferentialConstraint>
</Association>
<Association Name="CarrierToFlight" sap:content-version="1">
<End Type="RMTSAMPLEFLIGHT.Carrier" Multiplicity="1" Role="FromRole_CarrierToFlight"/>
<End Type="RMTSAMPLEFLIGHT.Flight" Multiplicity="*" Role="ToRole_CarrierToFlight"/>
</Association>
<Association Name="BookingFlight" sap:content-version="1" sap:label="Booking Flight Association">
<End Type="RMTSAMPLEFLIGHT.Flight" Multiplicity="1" Role="FromRole_BookingFlight"/>
<End Type="RMTSAMPLEFLIGHT.Booking" Multiplicity="1" Role="ToRole_BookingFlight"/>
<Principal Role="FromRole_BookingFlight">
</Principal>
<Dependent Role="ToRole_BookingFlight">
</Dependent>
</Association>
<Association Name="FlightBookings" sap:content-version="1">
<End Type="RMTSAMPLEFLIGHT.Flight" Multiplicity="1" Role="FromRole_FlightBookings"/>
<End Type="RMTSAMPLEFLIGHT.Booking" Multiplicity="*" Role="ToRole_FlightBookings"/>
<Principal Role="FromRole_FlightBookings">
</Principal>
<Dependent Role="ToRole_FlightBookings">
</Dependent>
</Association>
<EntityContainer Name="RMTSAMPLEFLIGHT_Entities" m:IsDefaultEntityContainer="true">
<EntitySet Name="BookingCollection" EntityType="RMTSAMPLEFLIGHT.Booking" sap:pageable="false" sap:content-version="1"/>
<EntitySet Name="CarrierCollection" EntityType="RMTSAMPLEFLIGHT.Carrier" sap:creatable="false" sap:deletable="false" sap:content-version="1"/>
<EntitySet Name="TravelagencyCollection" EntityType="RMTSAMPLEFLIGHT.Travelagency" sap:label="Travel Agencies" sap:searchable="true" sap:content-version="1">
<gp:collectionLayout display-order="0010" top-level="true"/>
</EntitySet>
<EntitySet Name="TravelAgencies" EntityType="RMTSAMPLEFLIGHT.Travelagency" sap:searchable="true" sap:content-version="1"/>
<EntitySet Name="TravelAgencies_DQ" EntityType="RMTSAMPLEFLIGHT.Travelagency_DQ" sap:searchable="true" sap:content-version="1"/>
<EntitySet Name="SubscriptionCollection" EntityType="RMTSAMPLEFLIGHT.Subscription" sap:content-version="1"/>
<EntitySet Name="NotificationCollection" EntityType="RMTSAMPLEFLIGHT.Notification" sap:creatable="false" sap:updatable="false" sap:deletable="false" sap:addressable="false" sap:content-version="1"/>
<EntitySet Name="FlightCollection" EntityType="RMTSAMPLEFLIGHT.Flight" sap:content-version="1">
<gp:collectionLayout display-order="0010" top-level="true"/>
</EntitySet>
<EntitySet Name="FlightCollection_DQ" EntityType="RMTSAMPLEFLIGHT.Flight_DQ" sap:content-version="1"/>
<AssociationSet Name="AssocSet_BookingCarrier" Association="RMTSAMPLEFLIGHT.BookingCarrier" sap:creatable="false" sap:updatable="false" sap:deletable="false" sap:content-version="1">
<End EntitySet="CarrierCollection" Role="FromRole_BookingCarrier"/>
<End EntitySet="BookingCollection" Role="ToRole_BookingCarrier"/>
</AssociationSet>
<AssociationSet Name="CarrierToFlight_AssocSet" Association="RMTSAMPLEFLIGHT.CarrierToFlight" sap:creatable="false" sap:updatable="false" sap:deletable="false" sap:content-version="1">
<End EntitySet="CarrierCollection" Role="FromRole_CarrierToFlight"/>
<End EntitySet="FlightCollection" Role="ToRole_CarrierToFlight"/>
</AssociationSet>
<AssociationSet Name="AssocSet_FlightBookings" Association="RMTSAMPLEFLIGHT.FlightBookings" sap:creatable="false" sap:updatable="false" sap:deletable="false" sap:content-version="1">
<End EntitySet="FlightCollection" Role="FromRole_FlightBookings"/>
33
<End EntitySet="BookingCollection" Role="ToRole_FlightBookings"/>

</AssociationSet>
<AssociationSet Name="AssocSet_BookingFlight" Association="RMTSAMPLEFLIGHT.BookingFlight" sap:creatable="false" sap:updatable="false" sap:deletable="false" sap:content-version="1">
<End EntitySet="FlightCollection" Role="FromRole_BookingFlight"/>
<End EntitySet="BookingCollection" Role="ToRole_BookingFlight"/>
</AssociationSet>
<FunctionImport Name="CheckFlightAvailability" ReturnType="RMTSAMPLEFLIGHT.FlightAvailability" m:HttpMethod="GET" sap:label="Check availability of flight" sap:action-for="RMTSAMPLEFLIGHT.Flight">
<Parameter Name="airlineid" Type="Edm.String" Mode="In" MaxLength="3"/>
<Parameter Name="connectionid" Type="Edm.String" Mode="In" MaxLength="4"/>
<Parameter Name="flightdate" Type="Edm.DateTime" Mode="In" Precision="0"/>
</FunctionImport>
<FunctionImport Name="GetAvailableFlights" ReturnType="Collection(RMTSAMPLEFLIGHT.Flight)" EntitySet="FlightCollection" m:HttpMethod="GET">
<Parameter Name="fromdate" Type="Edm.DateTime" Mode="In" Precision="0"/>
<Parameter Name="todate" Type="Edm.DateTime" Mode="In" Precision="0"/>
<Parameter Name="cityfrom" Type="Edm.String" Mode="In" MaxLength="20"/>
<Parameter Name="cityto" Type="Edm.String" Mode="In" MaxLength="20"/>
</FunctionImport>
<FunctionImport Name="GetFlightDetails" ReturnType="RMTSAMPLEFLIGHT.FlightDetails" m:HttpMethod="GET" sap:action-for="RMTSAMPLEFLIGHT.Flight">
<Parameter Name="airlineid" Type="Edm.String" Mode="In" MaxLength="3"/>
<Parameter Name="connectionid" Type="Edm.String" Mode="In" MaxLength="4"/>
</FunctionImport>
<FunctionImport Name="GetAgencyDetails" ReturnType="RMTSAMPLEFLIGHT.Travelagency" EntitySet="TravelagencyCollection" m:HttpMethod="GET" sap:action-for="RMTSAMPLEFLIGHT.Travelagency">
<Parameter Name="agency_id" Type="Edm.String" Mode="In" MaxLength="8"/>
</FunctionImport>
<FunctionImport Name="UpdateAgencyPhoneNo" ReturnType="RMTSAMPLEFLIGHT.Travelagency" EntitySet="TravelagencyCollection" m:HttpMethod="PUT" sap:action-for="RMTSAMPLEFLIGHT.Travelagency">
<Parameter Name="agency_id" Type="Edm.String" Mode="In" MaxLength="8"/>
<Parameter Name="telephone" Type="Edm.String" Mode="In" MaxLength="30" Nullable="true"/>
</FunctionImport>
</EntityContainer>
<atom:link rel="self" href="https://webidequal-sapwebide.dispatcher.staging.hanavlab.ondemand.com/destinations/GM6/sap/opu/odata/iwfnd/RMTSAMPLEFLIGHT/$metadata"
xmlns:atom="http://www.w3.org/2005/Atom"/>
<atom:link rel="latest-version" href="https://webidequal-sapwebide.dispatcher.staging.hanavlab.ondemand.com/destinations/GM6/sap/opu/odata/iwfnd/RMTSAMPLEFLIGHT/$metadata"
xmlns:atom="http://www.w3.org/2005/Atom"/>
</Schema>
</edmx:DataServices>
</edmx:Edmx>
.
34
www.sap.com
2014 SAP SE. All rights reserved.

SAP, R/3, SAP NetWeaver, Duet, PartnerEdge, ByDesign, SAP
BusinessObjects Explorer, StreamWork, SAP HANA, and other SAP
products and services mentioned herein as well as their respective
logos are trademarks or registered trademarks of SAP SE in Germany
and other countries.
Business Objects and the Business Objects logo, BusinessObjects,
Crystal Reports, Crystal Decisions, Web Intelligence, Xcelsius, and
other Business Objects products and services mentioned herein as
well as their respective logos are trademarks or registered trademarks
of Business Objects Software Ltd. Business Objects is an SAP
company.
Sybase and Adaptive Server, iAnywhere, Sybase 365, SQL
Anywhere, and other Sybase products and services mentioned herein
as well as their respective logos are trademarks or registered
trademarks of Sybase Inc. Sybase is an SAP company.
Crossgate, m@gic EDDY, B2B 360, and B2B 360 Services are
registered trademarks of Crossgate AG in Germany and other
countries. Crossgate is an SAP company.
All other product and service names mentioned are the trademarks of
their respective companies. Data contained in this document serves
informational purposes only. National product specifications may vary.
These materials are subject to change without notice. These materials
are provided by SAP SE and its affiliated companies ("SAP Group")
for informational purposes only, without representation or warranty of
any kind, and SAP Group shall not be liable for errors or omissions
with respect to the materials. The only warranties for SAP Group
products and services are those that are set forth in the express
warranty statements accompanying such products and services, if
any. Nothing herein should be construed as constituting an additional
warranty.

H2G Using The Layout Editor of SAP Web IDE

Hochgeladen von

Dokumentinformationen

Originaltitel

Copyright

Verfügbare Formate

Dieses Dokument teilen

Dokument teilen oder einbetten

Freigabeoptionen

Stufen Sie dieses Dokument als nützlich ein?

Sind diese Inhalte unangemessen?

Copyright:

Verfügbare Formate

H2G Using The Layout Editor of SAP Web IDE

Hochgeladen von

Copyright:

Verfügbare Formate

SAP Web IDE

Provided by Customer Experience Group

H2G Using the Layout Editor of SAP Web IDE

First release of this guide

Adapted to SAP Web IDE version 1.5

Business Scenario ................................................................................................................................. 4

Background Information ...................................................................................................................... 4

Step-by-Step Procedure ....................................................................................................................... 4

This is the sequence of steps:

4.1 General Usage of the Layout Editor

You have to use the sap.m.Page control on the root level

Create a new Project

The first thing you need to do is to create a new Project

The Layout Editor has 4 different panels:

1) The View Pane

3) The Properties and Data Pane

3. Change the properties of a control.

Open the Property pane and change the following properties

And you get the following layout:

4. Add an additional Icon Tab Filter to the Icon Tab Bar

5. Select the Main.view.xml and open it with the Text Editor:

Select the following coding

and copy it between the last <IconTabFilter .></IconTabFilter> tags

and press delete.

Create a List View with Data Binding

2. Select the SAPUI5 View template and click next.

4. Add the oData model to the project.

b. Create the metadata.xml.

5. Open the Outline pane

You will get an empty List

8. Binding the oData model to the sap.m.List

9. Binding the oData model to the ObjectListItem

Bind the number property to the agencynum field

Bind the intro property to the URL field

You will get the following view:

Create a Form View using the HBox and VBox Container

Create a new SAPUI5View Component like in 4.4

Open the view with the Layout Editor.

Add a Label and an Input control to the second HBox

Add a Date Input Control

10. Add a Label and a Select Control to the fourth HBox

You get the following view:

2. Open the TravelAgency.view.xml with the Layout Editor

In the control pane open the Layout folder

10. Add an additional ObjectAttribute and bind it to TravelAgencies_DQ CITY

12. You get the following result:

<Property Name="departureTime" Type="Edm.Time" Precision="0" sap:label="Departure"/>

<End EntitySet="BookingCollection" Role="ToRole_FlightBookings"/>

2014 SAP SE. All rights reserved.

Das könnte Ihnen auch gefallen
