1. IMPORTANT SAFETY INSTRUCTIONS

1-1 NEMKO SAFETY INSTRUCTIONS

Please observe the following precautions to ensure personnel safety and reliable
equipment operation:

- The sound pressure level at the operators position according to IEC 704-1:1982
is equal or less than 70dB (A).
- Der arbeitsplatzbezogene Schalldruckpegel dieses Gerätes nach DIN 45635
beträgt 70dB (A) oder weniger.

For installation:

- The unit should be installed from service personnel.

- Dieses Gerät ist durch Elektrofachkräfte zu installieren.
- Upon installation, it should be ensured that the sum of the leakage current of the
UPS and the connected consumer does not exceed 3.5mA.
- Bei der Installation dieses Gerätes ist darauf zu achten, daβ die Ableitströme der
USV und der angeschlossenen Verbraucher den Maximalwert von 3.5 mA nicht
überschreiten.
- The socket-outlet shall be near the equipment and easily accessible.
- Die Gerätesteckdose muβ nahe dem Gerät angebracht und leicht zugänglich
sein.

Other safety instructions:

- The UPS contains voltages which are potentially hazardous. All repairs should
be performed by qualified service personnel. The UPS has its own internal
energy source (Battery). The output receptacles may be alive even when the UPS
is not connected to the mains.
- Die USV enthält Spannungen die möglicherweise gefährlich sind. Alle
Reparaturen sollten nur von ausgebildeten Monteuren durchgeführt werden. Die
USV hat eine interne Stromversorgung (Batterien). Die Ausgangsanschlüsse
können daher unter Strom stehen auch wenn die USV nicht an das
Versorgungsnetz angeschlossen ist.
- When replacing batteries, always use the same type and quantity as the previous
one. Batteries of:
GES302N / 3KVA: HR9-12 (BB), HR1234WF2 (CSB)
GES202N / 2KVA: GP1270 or GP1272F2 (CSB), BP7-12 or
BP7.2-12 (BB), NP7-12 (Yuasa), RT1270 (Ritar)

1-1
 GES102N / 1KVA: GP1270 or GP1272F2 (CSB), BP7-12 or
BP7.2-12 (BB), NP7-12 (Yuasa), RT1270 (Ritar)

- Falls Sie die Batterien austauschen, verwenden Sie bitte ausschlieβlich die
gleiche Anzahl und die folgenden Batterietypen:
GES302N / 3KVA: HR9-12 (BB), HR1234WF2 (34W)
GES202N / 2KVA: GP1270 or GP1272F2 (CSB), BP7-12 or
BP7.2-12 (BB), NP7-12 (Yuasa), RT1270 (Ritar)
GES102N / 1KVA: GP1270 or GP1272F2 (CSB), BP7-12 or
BP7.2-12 (BB), NP7-12 (Yuasa), RT1270 (Ritar)

- Do not dispose the battery or batteries in fire as this may explode.

- Werfen Sie niemals die Batterien in das Feuer, die Batterien könnten
explodieren.
- Do not open or mutilate the battery or batteries as released electrolyte is toxic
and harmful to skin and eyes.
- Öffnen oder beschädigen Sie nicht die Batterien, ausflieβendes Elektrolyt ist
schädlich für Haut und Augen.
- A battery can present a risk of electric shock and high short circuit current. The
following precaution should be observed when working on batteries.
‘ Remove watches, rings or other metal objects.
‘ Use tools with insulated handles.
- Eine Batterie kann eine Gefahr eines elektrischen Schlages und sehr groβer
Kurzschluβ ströme beinhalten. Folgende Vorkehrungen sollten getroffen
werden, wenn Sie mit der Batterie arbeiten.
‘ Entfernen Sie Uhren, Ringe und andere metallische Objekte.
‘ Verwenden Sie Werkzeug mit isollierten Griffen.
- The equipment is to be operated by fully trained personnels.
- Diese Gerät ist nur durch unterwiesenes Personal zu bedienen.
EC conformity declaration
- These devices comply with the regulations of the following guide-lines:
- 73/23/EEC guide-line of the Council for approximation of the legal
regulations of the EC countries concerning the electrical apparatus within certain
voltage tolerances, modified by the guide-line RL 93/68/EEC of the Council.
- 89/336/EEC guide-line of the Council for approximation of the legal regulations
of the EC countries concerning the electromagnetic compatibility, modified by
the guide-lines RL 91/236/EEC,... and 93/68/EEC of the Council.
- The compliance with the following standards proves the conformity:
€ EN 62040-1-1
€ EN 55022/EN 55011, class B.
1-2
2. INTRODUCTION

2-1 THEORY OF OPERATION

The main topology of the UPS consists of bypass path, AC-DC converter, DC-AC
inverter, battery charger, DC-DC converter, control circuit and detection circuit.
Moreover, the intelligent power management software is also optional. The
function and efficiency are superior to the traditional UPS.

Description of block diagram

BYPASS

PFC Control
Circuit LED Board Control Board

To Control Board
To Auxiliary Power

Breaker Relay BYPASS

RELAY
EMI AC-DC Double
AC I/P Half-bridge DC-AC Inverter AC O/P
Filter Booster

Battery Bank

Charger DC-DC Converter

To Control Board

To Control Board
Auxiliary
To External Battery Bank Power

Fig2-1 is the hardware block diagram of the UPS.

The UPS operation is described as below:

When the utility power is applied into the UPS, it was divided into two ways after
going through the breaker and EMI filter. One way is connected to AC-DC
converter which converts the utility AC power into a DC voltage which is called
DC-BUS voltage then divides into two paths. One path goes to charger which
converts the DC-BUS voltage into a proper DC voltage to charge the UPS battery.
The other path goes into DC-AC half bridge inverter. The other way works as a
bypass path. The bypass relay near the output will choose either the bypass path or
inverter output. In general, the UPS will internally do the self-diagnosis. If there is
no problem, the bypass relay will choose the inverter output. This is so called
“ON-LINE mode”.

2-1
 In case the utility power failure, the AC-DC converter and charger will be off duty.
The DC-DC converter works and converts the battery voltage into DC-BUS
voltage. The DC-AC inverter converts the DC-BUS voltage into AC voltage. This
is so called “ON-BATTERY mode”.

The auxiliary power circuit supplies the designated power to all the control
circuits.

Because the DC-AC inverter is always working, the DC-DC converter can work
rapidly and replace the AC-DC converter while the utility power fails. Furthermore,
the bypass relay continuously keeps in the position of inverter output to supply the
regulated power for the load. There is no power failure to loading equipment.

„ Description of each block

To make the service personnel clearly understand the function of our UPS, each
block is described in detail as below.
ƒ Input Breaker:
Protect UPS suffers from serious damage under abnormal condition. Also,
prevent the breaker of distribution panel from tripping while UPS fault
happens.
ƒ EMI Filter:
The EMI (Electro-Magnetic Interference) filter can suppress the noise either
coming from the utility power to UPS or out of UPS to the utility power.
ƒ AC-DC Converter:
It is a double-voltage boost converter with PFC (power factor correction)
function. It forces the current drawing from the utility power to be in phase
with the input voltage and regulate the output DC voltage to be about 380V.
ƒ PFC Control Circuit:
By use of this control circuit, the current drawing from the utility power could
be in phase with the input voltage. It also make the UPS has a wide input
voltage range.
ƒ DC-BUS:
The output DC voltage of the AC-DC Converter and DC-DC Converter are
called DC-BUS voltage.
ƒ DC-AC Inverter:
This inverter converts the DC-BUS voltage into AC voltage which is in phase
with AC input voltage. It is a half bridge inverter.
ƒ Control Board:

2-2
 The control board consists of protection circuit, detection circuit and control
circuit, which control the output voltage to be a sine wave.
ƒ Bypass Relay:
It is used to select the output of UPS to be the input utility voltage or the
inverter output voltage.
ƒ DC-DC Converter:
It converts the battery voltage into DC-BUS voltage.
ƒ Battery Bank:
It is one set of batteries connected in series. According to the different capacity
of UPS, the battery bank has different number of batteries in series.
ƒ Charger:
It converts the AC voltage drawing from the utility power into DC voltage,
which properly charges the battery and keep it with full energy.
ƒ Aux. Power (Auxiliary Power):
This circuit converts either the output of charger or battery bank voltage into
±12V and 20V and supply the demand power of control circuits in the AC-DC
Converter, DC-AC Inverter and control board.
ƒ External Battery Charger:
To quickly charge the external battery after the UPS has been back-up, we
design the external charger. Its charging current is larger than the internal
charger on the power stage board of UPS. So, the external charger is only used
in extended type of UPS.

2-2 FEATURE
The UPS, available in 1KVA, 2KVA and 3KVA, is an advanced on-line UPS
providing reliable and consistent sine-wave quality power to vital equipment. It
supports personal computers, networks, servers, telecommunication equipment
and a variety of other facilities. With its outstanding protection features, the unit
keeps your applications safe and running smoothly at all times.
PFC (Power Factor Correction)
With this function, the investment in the capacity of circuit breakers can be
reduced, specially it will be highly regarded as an important feature in critical load
applications.
Complete Protection
On-line double conversion design, pure sine wave output and zero transfer time
provide best protection. With a built-in surge, spike and line noise protection, the
UPS prevents destructive hardware damage and extends system life. The EMI/RFI
filtering design prevents electrical noise from affecting computer operation and

2-3
data files. Besides, the UPS provides built-in Fax/Network cable (RJ11/RJ45)
jacks protecting your hardware from surge, spikes and line-noise which travel
along communication lines, therefore providing you a complete “back door”
protection.

Intelligent design
Integrated with a microprocessor, the UPS is able to perform intelligent functions.
The UPS triggers over-voltage protection function and transfers to “On- Battery
mode” even when utility voltage exceeds 280V. In addition, the UPS can accept
large voltage variation of 80V to 280V. Wide input voltage range means less
battery power usage frequency and longer battery life-span. Besides,
programmable outlet design, suitable for power management, is also included in
this unit.

Green function design

The operation in sleeping mode is designed to just keep charging which saves the
energy a lot.

User friendly interface

The UPS provides a variety of functions which meet users’ needs. Users can
instantly understand the status of the UPS via the informative LED display.
Audible alarms, bar meters and status indicators, such as battery replace indication,
UPS fault, line condition, overload etc. are simple and easy for user to understand.
Moreover, users can simply reset the circuit breaker instead of having to replace a
fuse in the event of output overload.

Network Management
Build-in communication interface port supporting RS232 protocols enhances the
reliability and manageability of the UPS over all major operating systems,
including Windows 95/98, Windows NT, Netware, UNIX, and others. Besides, the
UPS also supports the Simple Network Management Protocol and Hyper Text
Transfer Protocol via plugging a SNMP/HTTP adapter into the build-in SNMP
slot

2-4
2-3 SPECIFICATION
Model GES102N GES202N GES302N
Capacity 1KVA/700W 2KVA/1400W 3KVA/2100W
Rated Voltage 230V
175V∼280V(Full Load)；
Voltage Range
Input 80V~175V(100% to 50% Load de-rating Linearly)
Frequency 50/60Hz (±5.0 Hz)
Power Factor ≥0.97
Voltage 230V
Frequency 50/60Hz
Voltage Regulation +2%
Frequency Accuracy +0.05 Hz
Wave Form Pure Sine Wave
Output Transient Response +8% (10%∼90% Linear Load)
THD ≤3%(Linear Load); ≤6%(Computer Load)
Overload Capacity 105%-125% for 3mins; 125%-150% for 30secs; >150% for 1sec
Crest Factor 3:1
Efficiency (AC-AC) ≥ 87%
Outlet Receptacle IEC320×4×1 IEC320×4×2
Battery Voltage 36 V 72V 72V
Battery Type
12V/ 7Ah 12V/ 9Ah
(Lead acid)
Back-up Time
Battery 5mins (700W) 5mins (1400W) 5mins (2100W)
(Typical)
8 Hours After
8 Hours After Complete Discharge to
Recharge Time Complete Discharge
Recover 90%
to Recover 80%
Transfer Time Transfer Time Zero
On-line、Bypass、On-battery、Overload、Battery Low、Fault、
LED Status
LED Battery Replace、Battery Level、Load Level
Alarm Buzzer
DB9 RS232
Interface
SNMP Slot External Internal
Noise (At 1 Meter) 40dBA 47dBA
Operating
Environment 0-40℃
Temperature
Humidity 0%~90% (Non-Condensing)
Safety Nemko / GS
Safety Approval EMC CISPR PUB 22 Class A
Lightning IEEE 62.41 Category A
Battery Start Yes
Extended Battery
Others Yes
Bank
Long Time Model Yes (Optional)
Dimension 140 x 363 x 242 / mm 140 x 422 x 373 / mm
(W×D×H) 5.5 x 14.2 x 9.5 / inch 5.5 x 16.6 x 14.7 / inch
Appearance
Typical 15kg / 33 lb 29kg / 63.9 lb
Weight
Long Time 6kg / 13.2 lb 15.2kg / 33.5 lb
z All specifications are subject to change without prior notice.

2-5
 2-4 ANNOTATION AND SYMBOL
The two signs shown on the manual indicating important instruction need to be
followed.

!
Read before Operation Maybe Dangerous/Follow Instructions

PROTECTIVE GROUNDING TERMINAL: A terminal which must be

connected to earth ground prior to making any other connection to the
equipment.

This symbol indicates the word “phase”.

This symbol indicates the principal on/off switch is in the “ON” position.

This symbol indicates the principal on/off switch is in the “STANDBY”

position.

2-5 FRONT PANEL

Operation Panel

Operation panel

2-6
 Front Panel for 1KVA Front Panel for 2KVA or 3KVA
2-6 OPERATION PANEL

B. 6 B. 5

B. 7 B. 8
B. 11
A. 1 A. 2
B. 10
B. 9
B. 1
B. 3
B. 2
B. 4
Operation Panel
Operation Panel
A. Button:

(1) ：1/TEST: The button is used for turning on the UPS, it also can perform
the test function in “ON-LINE mode”. In backup mode, this button can turn
off the buzzer for silence.

(2) : The button is used for turning off UPS.

B. LED display:

(1) Bypass: The LED indicates UPS in “BYPASS mode”.

(2) Line: The LED indicates the condition of UPS input line. If the input voltage
is too low, too high or out of frequency this LED will flash. When line is
blackout or ultra high voltage (>300Vac), this LED will light off.
(3) ON Line: The UPS is running in “ON-LINE mode”.
(4) ON Battery: The UPS is running in “ON-BATTERY mode” (backup mode),
the internal batteries supply power.

(5) Level LEDs: The four LEDs indicate the battery capacity in “ON-BATTERY
mode” or UPS load percentage in “ON-LINE mode”.

2-7
(6) Battery: “Level LEDs” shows the current battery capacity when the LED lights up.

(7) Load: “Level LEDs” shows the UPS load level when the LED lights up.

(8) Battery low: The LED indicates the battery in battery low condition.

(9) Battery replace: The LED indicates the batteries are weak and suggest the
user to replace the batteries.

(10) Overload: The LED indicates UPS’ load exceed the rating, after a limited
period, the UPS will transfer to “BYPASS mode” and the LED will still light
on to alarm the user.

(11) Fault: The LED indicates that the UPS is fault. This LED Flash indicates that
the UPS is overheat.

2-8
2-7 REAR PANEL
The rear panel is explained as follows: (Please refer to Fig 2-2, 2-3)

Fig 2-2 (1KVA) Fig 2-3 (2KVA, 3KVA)

(1) OUTPUT RECEPTACLES: The UPS supplies AC power to the load via
these receptacles.
(2) I/P BREAKER: This is used to prevent high input current from the UPS.
(3) INPUT SOCKET: AC input utility power supplies to the UPS via the socket.
(4) TVSS (Transient Voltage Surge Suppressor) (RJ-45/RJ-11 SURGE
PROTECTOR): These connectors are used to prevent damage from surge,
noise and spike traveling form telephone or network line.
(5) COMMUNICATION INTERFACE (RS-232): The communication port is
used to communicate PC and UPS. Please refer to section 4 for more
information.
(6) Fan: DC fans for cooling purpose.
(7) External Batteries Connector: Used for connecting external battery cabinets
to extend back up time.
(8) SNMP SLOT: SNMP adapter can be inserted into this port for monitoring
UPS status via network.

2-9
2-8 INSTALLATION
Unpacking
z Please read this user manual before installing the UPS.
z This UPS contains batteries which are potentially hazardous to user, even
when the UPS is not connected to the utility power.
z Before unpacking the UPS, check the packing box. If there is any visible
damage, contact your dealer at once.
-This unit is to operate by any individuals with previous training.
-This unit should be installed by service personnel.

Before Installation
z Avoid exposing the UPS to direct sunlight or other heat source. The UPS
should be facing away from direct sunlight glare.
z Choose a well-ventilated area to position your UPS to allow adequate
dissipation of heat.
z Ensure the UPS surrounding area is clean and free from moisture.
z Do not put heavy objects on the cable or power cord.

Installation
Notice:
- AC output need a disconnect device such as a breaker which has to be provided
by others.
- The wire length of output power cord connected to the output receptacle or
pressure terminal should be less then 10 meters.
- The UPS provide with pressure terminal connector for field installed wiring,
the terminal connector should be applied a 13.8 lb-in (1.554 N-m) of
tightening torque.
- The over current protection and short circuit protection for the AC output is
provided by internal circuits of UPS and breaker.
- Concerning about the battery voltage, ambient temperature and other
specifications of the UPS, please refer to the specification section of this
manual.
- Servicing of batteries should be performed or supervised by personnel
knowledgeable of batteries and the required precautions. Keep unauthorized
personnel away batteries.
- When replacing batteries, replace with the same type and number.

2-10
1. Connecting to utility power (Refer to Fig 2-6, Fig 2-7)
(1) Connect the IEC plug of power cord to the IEC 320 connector on the UPS.
(2) Plug the other end of the power cord into a two-pole, three-wire, grounding
receptacle only. Avoid using extension cords and adapter plug.

After that, the fan (in rear panel) will run and all LEDs will light for about 2-3
sec. Meanwhile the CPU inside the UPS setups the initial parameters. User
also can check whether all LEDs are normal or not. The UPS is set in
“STANDBY mode” initially, after a ‘beep’ is heard, the load LED lights on
and the line LED shows AC utility status. Shown as (Fig 2-4)

Fig 2-4 Stand-By Mode

2. Charging the battery
(1) The battery charger of the UPS automatically charges the battery whenever
the power cord of UPS is connected to a acceptable utility power.
(2) When UPS is running for the first time, charge the UPS for at least 6 hours to
ensure batteries inside are fully charged before operation.
(3) You may immediately use the UPS without having to wait for the batteries to
be fully charged. However, it is advisable not to do this as UPS will have a
shorter back-up time than expected if such action is taken.
3. Connecting the battery bank
(1) Utilize the battery connection cable packed with the battery bank.
(2) Connect on one end of the cable to the external battery connector of UPS, and
the other end to that of the battery bank.
(3) Warning: For safety reason, the manufacturer suggests that ONE UPS
CONNECTS AS MANY AS FIFTEEN EXTERNAL BATTERY BANKS.
(4) The battery banks should be installed by service personnel.
A. According to UL 1778 safety requirement: in order to remove the battery
power cord emergently, please plug in the power cord directly.
B. According to EN50091-1-1 safety requirement: besides plugging in the
battery power cord, the battery power cord needs to be fixed with the
screws.

2-11
 Fig. 2-5.1 (1KVA) Fig. 2-5.2 (2KVA/ 3KVA)

Fig 2-5 UPS Connected to External Battery Bank

Model name Batt V.

1KVA 36V 2SET

2KVA 72V 1SET

3KVA 72V 1SET

Table 2-1 External Battery Cabinet Classification

4. Connecting the load

-Calculate power consumption of your loads to ensure that the overload condition
will not happen.
-Plug the power cord of the equipment into the output receptacles on the rear panel
of the UPS.

-Turn on the equipment connected to the UPS.

-Caution: Do not connect a laser printer to the UPS.

! -Caution: Do not connect the UPS to generator.

2-12
5. Connecting the RS-232
Connect the interface signal cable between the RS-232 port on the rear panel of
UPS and COM1 or COM2 of computer if necessary.

The D-sub 9 connector can work as a RS-232 communication port depending on

the type of cable and software used. Refer to section 4 for more information.

UPS Connection for 1KVA :( Refer to Fig 2-6)

(1) Connected to RS-232 cable
(2) Provides power to PC.
(3) Connected to utility power.

Fig 2-6
UPS Connection for 2KVA or 3KVA: (Refer to Fig 2-6)
(1) Connected to RS-232 cable
(2) Provides power to PC.
(3) Connected to utility power.

Fig 2-7
2-13
2-9 OPERATION
1. Cold start when utility is not present
Even when there is no utility power, you can still turn on the UPS. Just press
the 1/TEST button and hold for 2~4 second, the UPS will start up after you
hear a “beep”. The battery LED and on-battery LED will light on and the UPS
runs on “ON-BATTERY mode”. Shown as (Fig 2-8)

Fig 2-8 On Battery Mode

2. Turning “ON” the UPS

When the utility power is acceptable for the UPS, you can normally turn on the
UPS after pushing the 1/TEST button and hold a few seconds until a “beep” is
heard. The bypass LED will extinguish after shortly light on. When the on-line
LED lights on, the UPS is running on “ON-LINE mode”. Shown as (Fig 2-9)

Fig 2-9 On-Line Mode

3. Turning “OFF” the UPS

Push the button for turning off the UPS, when a “beep” is heard release
your press. After a few seconds the UPS is off.
The UPS will keep charging when UPS is in “STANDBY mode” even though
the button has been pressed. To fully turn off the UPS, it is advised to
unplug the power cord. Refer to (Fig 2-3).

2-14
4. UPS self-test
If press the 1/TEST button when the UPS is in “ON-LINE mode”, it will make
the UPS shift to “ON-BATTERY mode” and automatically perform a self-test
for about 10 seconds. (Shown as Fig 2-10) The self-test function will check the
condition of the battery. After self-test is finished and test is O.K, the UPS will
return to “ON- LINE mode”.

Fig 2-10 UPS Self-Test

5. Silence function
The buzzer can be turned “On” or “Off” by toggling the 1/TEST button when
the UPS is in “ON-BATTERY mode”.

6. If certain abnormal condition occurs, the UPS will send the

following messages:
ON-BATTERY mode: When the UPS is in “ON-BATTERY mode”, the on-
battery LED will light on, buzzer beep half second every 2 seconds and then the
UPS will start supplying power to load through batteries. Shown as (Fig 2-11)

Fig 2-11 On-Battery Mode

7. De-rating power
In the range of 80Vac to 175Vac, the UPS load capacity will decrease. This
function provides a wider operating power voltage range.

2-15
2-10 PLACEMENT
To stably install the UPS of 2 and 3kVA models, you must set up UPS with
supporting stands.

The installation method is as shown below:

Fig 2-12 Erect the UPS with supporting stands

2-16
3. ASSEMBLING
3.1 MECHANICAL DRAWING FOR 1KVA

3-1
3.2 MECHANICAL DRAWING FOR 2/3 KVA

3-2
3.3 WIRING DIAGRAM FOR 1KVA

3-3
3.3 WIRING DIAGRAM FOR 2/3KVA

3-4
Note: The entire standard and extended model are basically the same design. Remove the
internal battery of standard model and add another charger board. This additional
charger is connected in series with the original one but only has higher charging current.
That means, extended model has the same function as standard type but only can use
higher charging current to charge the external battery pack.

3-5
4. COMMUNICATION INTERFACE

4-1 RS-232
The UPS provides RS-232 protocols in one D-sub 9 connector. Using proper
UPS management software and cable, the UPS can be managed over
LAN/intranet/internet environment. The pin assignment of the D-sub 9 connector
is defined as follows:
ASSIGNMENT DESCRIPTION
PIN
RS-232
D C
1

2 UPS TxD(typical RS-232 level)

3 UPS RxD(typical RS-232 level)

R h d (5 12V)
4

5 GND
GND
6

7 Reserved for PNP

R d
8

Pin2 : PC receives line RS-232 data from UPS.

6 7 8 9
Pin3 : PC transmits line RS-232 data to UPS.
1 2 3 4 5
Pin5 : Signal ground.
Pin7 : Reversed for plug and play function. Fig 4-1 Pin Assignment

The RS-232 communication port provides the following functions:

1) Monitoring charger status
2) Monitoring battery status and condition
3) Monitoring inverter status
4) Monitoring UPS status
5) Monitoring the utility status
6) Providing the power switch function for computer to turn on/off the utility on
schedule for power saving

4-1
 The UPS data is provided at 2400 bps baud rate and made up of 8-bit, 1 stop-bit
and no parity bit. All information is encoded in ASCII format.
HARDWARE:
BAUD RATE----------------2400 bps DATA LENGTH------------8 bits
STOP BIT--------------------1 bit PARITY----------------------NONE
CABLING:
Standard D-sub 9 cable (UPS side: male, PC side: female)

4-2 SNMP
SNMP is short for simple Network Management Protocol.
Most of the network management programs implement the SNMP NMS
(Network Management Station) to manage the network the network devices.
This UPS provides an SNMP slot for your farther use.
Features of the UPS SNMP Card:
1. Auto-detective 10/100M network speed.
2. TCP/IP, UDP, HTTP, ICMP, ARP, Telnet, BOOTP, DHCP, FTP and SNMP
implemented.
3. Remote firmware upgraded (FTP) and configuration.
4. Web server inside to allow web browser to monitor / control the UPS.
5. VT100 terminal mode / Telnet for SNMP’s configuration.
6. PS/2 for external environmental sensor box.
7. Environmental temperature and humidity monitoring.

4-2
5. MAINTENANCE AND TROUBLESHOOTING

5.1 MAINTENANCE
z Normally, the life of battery is 3 years. But extreme operating
condition and environment may shorten its life-span.
z To replace batteries, contact qualified personnel.
z When UPS has been unused for a period of time, the batteries will
discharge slightly. It is recommended to charge the UPS once every 3
months.
z Use a vacuum cleaner to get rid of any dust that may rest on the
opening of the fan.
z Unplug the UPS when it is not used for a long time.
z When cleaning the plastic case or front panel, only use a soft, dry cloth.
If the case or front panel is very dirty, use a neutral, non-abrasive
detergent. Do not use alcohol or ammonia based solutions.
z When moving your UPS, always handle it with care.
z Avoid spilling liquid on the UPS.
z The equipment should be repaired and installed by individuals with
previous training.
When installing this equipment, it should be noted that the leakage current
of the UPS and its loads must not exceed 3.5mA in total for safety.

5.2 PCB INTRODUCTION

z Power stage PCB:
The power stage PCB consists of
1. Inverter power transistors and it related circuits.
2. PFC power transistors and it related circuits.
3. Charger circuit
4. Auxiliary Power Supply: It supplies the demanded power of all
the control circuits.
5. D/D power transistors s and it related circuits.
z LED PCB:
Provide UPS status indication.
z EMI PCB:
The EMI (Electro-Magnetic Interference) PCB can suppress the noise
either coming from the utility power to UPS or out of UPS to the utility
power.
Both 2 and 3 KVA models have Input / output EMI Board.

5-1
 z Control PCB:
The main functions of the control PCB is listed as below.
1. Detection of the input voltage and phase lock loop.
2. Detection and feedback of output voltage.
3. Detection of battery voltage.
4. Load power detection of the inverter and bypass path; overload
protection.
5. Over temperature detection.
6. Connecting the LED to display the UPS status.
7. Offering the driving signal to the inverter driver circuit.
8. Offering RS-232 communication signals.
9. Offering soft start function.
10. Enable and disable the beeping of the buzzer.
11. Control of the bypass relay.
12. Shutdown UPS.
13. Detection of the utility power failure.
14. Output frequency (50Hz/60Hz) selection of Auto detection for the
output frequency according to the frequency of AC input voltage.

PCB LIST

1KVA 2KVA 3KVA

INPUT/OUTPUT
5505000618 5505000619 5505000621
EMI BOARD

CONTROL
5505000702 5505000702 5505000702
BOARD

POWER STAGE
5505001116 5505001117 5505001118
BOARD

FUSE BOARD 5505001032 5505001032 5505001021

LED BOARD 5505000620 5505000620 5505000620

5-2
5.3 TROUBLESHOOTING

WARNING MESSAGE
Indicate the UPS is under abnormal condition follow the instruction below to
solve the problem:

5.3-1 Input abnormal:

In case that failure is happened
and utility is too low or too high,
line LED will flash.

Input Abnormal

5.3-2 Battery Replace:

This LED function is to alert user that the
batteries should be replaced. When the
microprocessor in the UPS detects a
battery fault, the UPS alarm will beep for
0.2 seconds and interrupted by an interval
of 2 seconds.

1. Recharge the batteries for at least 8

hours.
Battery Replace
2. If problem remains please replace
the batteries.

5.3-3 Battery Low:

This function is to inform user the
remaining power capacity of the batteries.
When batteries reach a low level condition,
the UPS alarm will beep half second every
1.2 seconds until running out of battery
capacity.

Battery Low

5-3
5.3-4 Overload Turn into Bypass:
If the load exceeds the allowable rating,
after a limited period, the overload LED
will light on and buzzer continuous
beeping to warn the user. The user should
unplug some loads to release the overload
condition.

Remove some critical load. Overload turn into bypass

5.3-5 Short Circuit:

When the output of the UPS shorts in
“ON-LINE mode”
or “ON-BATTERY mode”, the UPS will
shut down (without output voltage). As
soon as the short circuit is happened, the
overload LED will flash and the UPS alarm
will sound continuously. When remove short
circuit, the UPS output will recover. If short
circuit is happened in “BYPASS mode”, Short Circuit
the UPS will protect itself by tripping the input
breaker and shut down. Remove critical load.

※ UPS internal fault

If the following conditions occur, the UPS fails. At this time the UPS will
transfer to “BYPASS mode”. The bypass LED and fault LED will light on and
alarm continuously. If utility is too low or too high the UPS output will be
disabled.
FAULT MESSAGE
Following information indicates various symptoms.
Use this information to determine what factors cause the problem.
1. Alarm will sound to alert user that the UPS requires attention.
2. One or more additional load/battery level LED indicators will illuminate to
provide a diagnostic aid to the operator, described as below:

When the UPS inner components overheat, the UPS will protect itself by
thermo-switches. This status is so-called “O.T.P”
When under (or over) voltage is happened in the UPS output. This kind of fault
5-4
 will be detected by the microprocessor in the UPS and is so-called “U.V.P”
(“O.V.P”).
When under (or over) bus voltage is happened in the UPS and is so-called “Bus
U.V.P” (“Bus O.V.P”).

5.3-6 Charge Voltage too High:

1. Check the charge voltage is over limit
(87Vdc for 2, 3KVA models, 43.5Vdc
for 1KVA model) or not. If so,
you must shutdown UPS to prevent
overcharging the battery.
2. Change the power stage PCB.
Charge Voltage too High

5.3-7 O/P OVP: O/P Over Voltage

Protection
Output voltage is abnormal.
1. Restart the UPS
2. If problem remains replace the power
stage PCB.
Output OVP

5.3-8 O/P UVP: O/P Under Voltage

Protection
Output voltage is too low.
1. Restart the UPS
2. If problem remains replace the power
stage PCB. Output UVP

5.3-9 BUS OVP: BUS Over Voltage

Protection
1. Restart the UPS
2. If problem remains replace the power
stage PCB.
BUS OVP

5-5
5.3-10 BUS UVP: BUS Under Voltage
Protection
1. Restart the UPS
2. If problem remains replace the power
stage PCB.

BUS UVP

5.3-11 OTP: Over Temperature Protection

If temperature is too high, the buzzer
continuous beeping to warn user.
Check cooling fan.

OTP

5.3-12 Output OVP & Input Voltage

Abnormal
Refer to 5.3-1 and5.3-7

O/P OVP & Input

Voltage Abnormal

5.3-13 Output UVP & Input Voltage

Abnormal
Refer to 5.3-1 and 5.3-8

O/P UVP & Input

Voltage Abnormal

5.3-14 Bus OVP & Input Voltage

Abnormal
Refer to 5.3-1 and 5.3-9

Bus OVP & Input

Voltage Abnormal
5-6
5.3-15 Bus UVP & Input Voltage
Abnormal
Refer to 5.3-1 and 5.3-10

Bus UVP & Input

Voltage Abnormal

5.3-16 OTP & Input Voltage Abnormal

Refer to 5.3-1 and 5.3-11

OTP & Input

Voltage Abnormal

5-7
