SPARE PARTS CATALOGUE

CD-ROM 'ELCAT' 1/2003 02.03.2006

6 WG-160
ZF parts list no.: 4656 056 018

customer: MISTA
 ZF-ELCAT technical information sheet CD 1/2003 02.03.2006
sheet 2

parts list: 4656 056 018 6 WG-160 / / MISTA

item text mod. no.

A10 KUNDENNAME: MISTA *
LAND/ORT: POLEN
KUNDEN-NR.:
A50 ZFP-PROJEKT-NR.: 46742
B04 MOTORDREHMOMENT(NM) 690 K02059/02
MAX.ZUGKRAFT 1. GANG ¬N|:MAX. 164 584 K02059/02
FAHRZEUGDATEN: * K02059/02
FAHRZEUG-IDENT-NUMMER: K02059/02
MOTORLEISTUNG(KW) 123 K02059/02
WEITERE FLB NEIN K02059/02
FAHRZEUGART: 373 GRADER K02059/02
FAHRZEUGANWENDUNG GRADER RD-165 K02059/02
FAHRZEUGMASSE LEER (TO): 13 K02059/02
FAHRZEUGMASSE BELADEN(TO) K02059/02
FAHRLEISTUNGSBERECHNUNG: 4656 706 549 K02059/02
BEI DREHZAHL(1/MIN) 2200 K02059/02
FAHRZEUG: GRADER K02059/02
MOTOR: CUMMINS 6BTA 5,9 K02059/02
BEI DREHZAHL 1500 K02059/02
REIFENGROESSE K02059/02
REIFENRADIUS(M): 0,600 K02059/02
FESTBREMSDREHZAHL(1/MIN): K02059/02
ACHSUEBERSETZUNG: 20,66 K02059/02
ENDGESCHWINDIGKEIT(KM/H) 38 K02059/02
V-MAX.1.GANG ¬KM/H|: 5 K02059/02
E02 GETRIEBEDATEN:
E04 GETRIEBETYP: 6 WG 160
E40 UEBERSETZUNG VORW.1.GANG 5,202 *
1.GANG RUECKWAERTS: 4,939
2.GANG VORWAERTS: 3,367
5.GANG VORWAERTS: 0,944
3.GANG VORWAERTS 2,191
6.GANG VORWAERTS: 0,611
4.GANG VORWAERTS: 1,418
2.GANG RUECKWAERTS: 2,078
3.GANG RUECKWAERTS: 0,895
E70 WANDLER: W300 * K02059/02
 ZF-ELCAT technical information sheet CD 1/2003 02.03.2006
sheet 3

parts list: 4656 056 018 6 WG-160 / / MISTA

item text mod. no.

WANDLER-TEILE/BASIS.NR. 4168 030 194 K02059/02
ANFAHRWANDLUNG: 1,91 K02059/02
LEITRADFREILAUF: OHNE K02059/02
WANDLERDURCHKUPPLUNG: OHNE K02059/02
F02 ANTRIEBSFLANSCH-TYP: DIN 120
ANTRIEBSFLANSCH: DIN
ANTRIEB: GELENKWELLENANBAU
F30 ABTRIEB: STANDARD
F31 ABTRIEB WATFAEHIG: NEIN
F32 ABTRIEBSFLANSCH-TYP: DIN 150
ABTRIEBSFLANSCH ANTRIEBS.:DIN
SCHRAUBEN: 8 X M12 X 50
ABTRIEB ANTRIEBSSEITE: ACHSABSCHALTUNG OHNE *
F36 SCHRAUBEN: 8 X M12 X 50
ABTR.FLANSCH SCHALTUNGSS.:DIN
ABTRIEB SCHALTUNGSSEITE: MIT FSG-90
ABTRIEBSFLANSCH-TYP: D = 150
G02 MITNEHMER/PROFIL: SAE B 16/32 DP 13 Z
FLANSCH: SAE B 2/4 LOCH
ABSCHALTUNG: OHNE
NEBENABTRIEB: 1 PTO KOAX./MOTORABHAENG.*
K02 ANSCHLUSSSTECKER: BAJONETT
ARBEITSDRUCK: 16 + 2 BAR
SPANNUNG: 24 VOLT
SCHALTUNG: HSG 94 *
K78 IMPULSZAHL/UMDR.ABTRIEB: 56
IMPULSZAHL/UMDR.MRK: 55
IMPULSZAHL/UMDR.TURBINE: 49
IMPULSZAHL/UMDR.MOTOR: 4 *
K80 ELEKTRIKTEILE: LIEFERUNG MIT GETRIEBE
K82 TEMPERATURGEBER N. WANDLER: MIT (UEBER TEMP.ANZEIGE)
K84 GRUPPE LOSTEILE: 4656 183 021
K86 STEUERUNG: EST 37
K91 BORDNETZSPANNUNG: 24 VOLT
K94 FAHRSCHALTER: VTS-3
K96 DISPLAY INTEGRIERTE MONTAGE
L64 VERKABELUNG: MIT
 ZF-ELCAT technical information sheet CD 1/2003 02.03.2006
sheet 4

parts list: 4656 056 018 6 WG-160 / / MISTA

item text mod. no.

M02 GETRIEBE-OPTIONEN:
M50 TACHO: ELEKT.ANSCHL. EST-37
M60 OELSTANDSROHR/ANBAU: ANTRIEBSSEITIG *
LIEFERUNG OELSTANDSROHR: MONTIERT AM GETRIEBE
OELSTANDSROHRVARIANTE: A1/KURZ/GERADE
M80 FILTERANBAU: GETRENNT
P06 NOTLENKPUMPE: OHNE
R02 GETRIEBEDOKUMENTATION:
R06 SCHNITTZEICHNUNG: 4656 554 002
R16 EINBAUZEICHNUNGSART: KUNDENSPEZIFISCH
R18 EINBAUZEICHNUNG: 4656 656 018
R24 GETRIEBESCHEMA: 4656 700 036
R28 OELSCHEMA: 4656 700 037
R96 EINBAURICHTLINIEN: 4657 700 078/079
S02 DOKUMENTATION STEUERUNG:
S04 ZEICHNUNG FAHRSCHALTER 1: 6006 635 005 K00214/01
ZEICHNUNG ANSCHLUSSPLAN.: 6029 701 275 K00214/01
ZEICHNUNG STEUERUNG: 6006 665 002 * K00214/01
ZEICHNUNG FAHRSCHALTER 2: 6006 700 529 K00214/01
ZEICHNUNG STROMLAUFPLAN: 6029 701 274 K00214/01
T06 OELSORTE GETRIEBE: SCHMIERSTOFFLISTE TE ML 03
GETRIEBEOELFUELLUNG: OHNE
OELEINFUELMENGE: CA. 21 LITER
T40 GESAMT-TROCKENMASSE: 377KG
T46 GRUNDIERUNG: 2 MAISGELB RAL 1006
V02 MONTAGEHINWEISE: SAP-DECKBLATT
 ZF-ELCAT summary of figures CD 1/2003 02.03.2006
sheet 5

parts list: 4656 056 018 6 WG-160 / / MISTA

figure part no. description technical information mod. no.

4656 130 050 00 4656 130 015 ENGINE CONNECT. K00120/03
4656 130 018 02 4656 130 407 ENGINE CONNECT. K00197/03
4166 030 013 00 4166 030 165 CONVERTER
4656 102 007 00 4656 102 015 INPUT K02571/01
4656 101 006 01 4656 101 019 GEARBOX HOUSING K02571/01
4656 101 006 02 4656 101 019 GEARBOX HOUSING K02571/01
4656 171 037 00 4656 171 055 COUPLING K1 K00962/05
4656 172 028 00 4656 172 040 COUPLING K2 K00962/05
4656 173 031 00 4656 173 048 COUPLING K3 K00962/05
4656 174 019 00 4656 174 038 COUPLING K4 K00962/05
4656 175 021 00 4656 175 035 COUPLING KV K00962/05
4656 176 026 00 4656 176 041 COUPLING KR K00962/05
4656 103 060 00 4656 103 008 OUTPUT
4656 103 061 00 4656 103 410 OUTPUT K00443/02
4656 109 060 00 4656 109 002 PARKING BRAKE K01329/02
4656 109 061 00 4656 109 408 PARKING BRAKE K01329/02
4656 154 003 00 4656 154 005 POWER TAKE-OFF
4656 106 020 00 4656 106 012 GEARSHIFT SYST. K01045/051
4657 106 021 00 4657 106 407 GEARSHIFT SYST.
4656 159 018 21 4656 159 016 GEARSHIFT SYST. KOMPLETT LIEFERBAR K01045/051
4656 159 018 22 4656 159 016 GEARSHIFT SYST. KOMPLETT LIEFERBAR K01045/051
4656 120 002 00 4656 120 005 PRESS.REGULATOR K02571/01
4656 122 001 00 4656 122 004 PRESS.OIL PUMP
4656 137 001 00 4656 137 004 EMCY.STEER.PUMP
4656 125 002 00 4656 125 006 IND.TRANSMITTER
4657 124 004 00 4657 124 003 TEMP.SENSOR
4656 138 002 01 4656 138 005 FILTER
4656 199 009 00 4656 199 402 LOOSE PARTS LOSTEILE FUER GRUPPE FILTER
4656 131 004 00 4656 131 003 OIL DIPSTICK
4656 183 008 00 4656 183 021 LOOSE PARTS
 CD 1/2003 02.03.2006
sheet 6
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 130 050 00 ENGINE CONNECT. * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 7

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 130 050 00 ENGINE CONNECT. (4656 130 015)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 330 008 1 CONVERTER BELL GG-25 9,140 P
020 0636 010 593 18 HEXAGON SCREW M 10 X 65 10.9 A3C 0,040 P
030 4657 330 037 H 1 COVER K00198/02 GG-25 19,000 P
040 0636 101 115 H 12 CAP SCREW M 10 X 50 8.8 A3C 0,030 P
050 0637 006 125 H 12 HEXAGON NUT M 10 8 A3C AU 0,010 P
060 4657 330 005 1 DIAPHRAGM IN 4657 330 003 S420MC WA 1,750 P
070 4657 330 039 H 1 INPUT SHAFT K00198/02 Z=24 IN 4657 330 038 ZF50 2,280 P
090 0636 016 221 H 12 HEXAGON SCREW M 12 X 18 10.9 A3C 0,030 P
100 0636 016 221 H 4 HEXAGON SCREW M 12 X 18 10.9 A3C 0,030 P
120 0750 116 221 1 BALL BEARING K00198/02 0,608 P
130 0630 532 157 1 V-RING K00198/02 JV 100 0,040 P
150 4627 303 027 1 WASHER 60X10 F500 0,210 P
160 0636 010 741 2 HEXAGON SCREW M 8 X 50 10.9 A3C 0,025 P
170 4644 330 006 1 TAB WASHER IN 1313 304 043 ST1303 0,009 P
 CD 1/2003 02.03.2006
sheet 8
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 130 018 02 ENGINE CONNECT. * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 9

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 130 018 02 ENGINE CONNECT. (4656 130 407)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
160 4644 330 128 1 INPUT FLANGE K00795/02 387.30 ZF50 1,460 P
220 4657 330 042 1 SCREEN SHEET K00197/02 S=2,0 FU270 0,090 P
230 0636 015 243 H 8 HEXAGON SCREW M 10 X 35 10.9 AU 0,030 P
 CD 1/2003 02.03.2006
sheet 10
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4166 030 013 00 CONVERTER * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 11

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4166 030 013 00 CONVERTER (4166 030 165)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4168 030 194 H 1 CONVERTER K00333/02 060700384009 W300 SEG 17,900 P
 CD 1/2003 02.03.2006
sheet 12
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 102 007 00 INPUT * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 13

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 102 007 00 INPUT (4656 102 015)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
110 4656 302 022 1 INPUT SHAFT Z=51 ZF7B 4,900 P
120 4656 302 010 1 TURBINE SHAFT ZF6 WW. A ZFN417 1,100 P
130 0630 513 099 1 SNAP RING SB 38 0,002 P
140 4656 302 013 1 INPUT GEAR Z=58 IN 4656 302 012 ZF7B 2,560 P
150 0630 501 054 1 RETAINING RING 90X3 0,040 P
160 0735 371 722 1 ROLLER BEARING 0,677 P
170 0735 371 722 1 ROLLER BEARING 0,677 P
180 0634 402 557 1 PISTON RING K01706/00 60 X 3 SH P KA NORMAU 0,010 P
190 4656 302 027 1 STATOR SHAFT Z=46 GGG-60 3,160 P
 CD 1/2003 02.03.2006
sheet 14
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 101 006 01 GEARBOX HOUSING * depending on parts list no.
 CD 1/2003 02.03.2006
sheet 15
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 101 006 02 GEARBOX HOUSING * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 16

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 101 006 01 GEARBOX HOUSING (4656 101 019)
4656 101 006 02 GEARBOX HOUSING (4656 101 019)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 201 017 1 HOUS.FRONT SECT K01278/02 KPL. IN 4656 201 018 87,200 P
030 4656 201 021 1 HOUS.REAR SECT. K00429/02 IN 4656 201 019 79,600 P
040 0631 306 816 H 2 CYLINDRICAL PIN 10 M 6X 24 16MNCR5 E 0,015 P
050 0636 101 708 44 CAP SCREW M 10 X 40 8.8 A3C 0,030 P
055 0636 115 004 H 7 CAP SCREW M 10 X 65 8.8 A3C 0,047 P
060 4656 301 016 1 SCREEN SHEET FU270 0,650 P
070 4656 301 017 1 SCREEN SHEET FU270 0,476 P
080 0636 101 644 H 4 CAP SCREW M 8 X 12 8.8 FE/ZN8 0,010 P
100 0730 365 092 1 TYPE PLATE AUSF.C IN 0730 365 091 EN 0,004 P
120 0750 131 027 1 BREATHER 0,010 P
150 4656 301 047 H 1 OIL FEED.HOUSG. K00997/05 D-TEIL IN 4656 301 046 EN A 4,100 P
160 0736 101 312 H 15 TORX SCREW M8X30 IN 0736 101 263 10.9 0,100 P
180 4656 301 023 1 GASKET 11950 0,015 P
190 0736 101 334 H 21 TORX SCREW M8X45 IN 0736 101 263 10.9 0,022 P
200 0736 101 335 H 4 TORX SCREW M8X60 IN 0736 101 263 10.9 0,027 P
212 0636 101 708 2 CAP SCREW M 10 X 40 8.8 A3C 0,030 P
220 4657 301 003 2 COVER GD-ALSI9CU3 0,130 P
230 0634 313 778 2 O-RING 76 X 3 FPM -70-10 0,004 P
240 0636 607 054 12 STUD K01105/00 M 8 X 25 10.9 A3C 0,010 P
260 0637 025 005 H 12 HEXAGON NUT M 8 10 A2C 0,007 P
270 4656 301 018 2 FIXING PLATE F270 0,090 P
290 1 SCREW PLUG 0,150 P
/010 0636 302 034 1 SCREW PLUG M 38X1,5 ST A3C WW 0,155 P
/020 0634 314 304 1 O-RING 35 X 2 FPM -70-10 WW 0,001 P
450 1 SCREW PLUG CM38X1,5 KPL.MIT O-RING 0,140 P
/010 0736 305 052 H 1 SCREW PLUG AUSFG.B IN 0736 305 053 WW 0,140 P
/020 0634 314 304 1 O-RING 35 X 2 FPM -70-10 WW 0,001 P
700 0501 210 712 1 SUCTION TUBE 0,855 P
720 0501 213 156 1 OIL TUBE K01278/02 0,630 P
730 0501 213 157 1 OIL TUBE K01278/02 0,725 P
780 0636 101 644 H 7 CAP SCREW K01278/02 M 8 X 12 8.8 FE/ZN8 0,010 P
790 0634 313 779 4 O-RING K01278/02 22 X 3 FPM -70-10 0,010 P
 CD 1/2003 02.03.2006
sheet 17
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 171 037 00 COUPLING * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 18

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 171 037 00 COUPLING (4656 171 055)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 371 033 1 SHAFT Z=68 IN 4656 371 031 ZF7B 8,600 P
020 0636 607 039 1 STUD M 10 X 16 8.8 0,013 P
030 4656 271 006 1 COUPLING P
/030 4656 371 047 1 DISC CARRIER 4,000 P
/040 4657 275 009 1 PISTON P
/060 0634 313 643 1 O-RING 75 X 3 ZFN 744 FPM-70-10 0,010 P
/070 0634 313 719 1 O-RING 142 X 3 ZFN 744 FPM-70-10 0,005 P
/080 4656 371 022 2 GUIDE RING 0,014 P
/090 0732 042 654 1 COMPR.SPRING 0,213 P
/100 0630 501 046 H 1 RETAINING RING 70 X 2,5 0,020 P
/105 0501 212 373 1 O.CLUTCH DISC 0,085 P
/107 0501 212 373 1 O.CLUTCH DISC 0,085 P
/110 0501 212 372 8 DISC 0,090 P
/120 0501 316 591 9 I.CLUTCH DISC 0,175 P
/130 0501 316 594 1 END SHIM 0,480 P
/140 1 SNAP RING P
0730 513 684 1 SNAP RING S=2,1 IN 0730 513 683 FEDE WW 0,030 P
0730 513 685 1 SNAP RING S=2,25 IN 0730 513 683 FEDEWW 0,040 P
0730 513 686 1 SNAP RING S=2,4 IN 0730 513 683 FEDE WW 0,035 P
0730 513 687 1 SNAP RING S=2,55 IN 0730 513 683 FEDEWW 0,040 P
0730 513 688 1 SNAP RING S=2,7 IN 0730 513 683 FEDE WW 0,040 P
0730 513 698 1 SNAP RING S=2,85 IN 0730 513 683 FEDEWW 0,040 P
0730 513 689 1 SNAP RING S=3,00 IN 0730 513 683 FEDEWW 0,043 P
0730 513 690 1 SNAP RING S=3,15 IN 0730 513 683 FEDEWW 0,045 P
0730 513 691 1 SNAP RING S=3,30 IN 0730 513 683 FEDEWW 0,048 P
0730 513 692 1 SNAP RING S=3,45 IN 0730 513 683 FEDEWW 0,050 P
0730 513 693 1 SNAP RING S=3,60 IN 0730 513 683 FEDEWW 0,043 P
0730 513 694 1 SNAP RING S=3,75 IN 0730 513 683 FEDEWW 0,055 P
0730 513 695 1 SNAP RING S=3,90 IN 0730 513 683 FEDEWW 0,055 P
0730 513 696 H 1 SNAP RING S=4,05 IN 0730 513 683 FEDEWW 0,059 P
0730 513 697 1 SNAP RING S=4,20 IN 0730 513 683 FEDEWW 0,061 P
150 0635 290 114 2 RUNNING DISC 0,060 P
160 0735 368 076 2 AX.NEEDLE CAGE 0,050 P
170 0635 290 012 2 AXIAL WASHER 1,000 P
180 0735 321 508 1 NEEDLE CAGE 0,200 P
190 4656 371 039 1 IDLER Z=26 IN 4656 371 038 ZF7B 2,560 P
200 0501 316 378 1 RETAINING RING 0,030 P
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 19

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 171 037 00 COUPLING (4656 171 055)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
210 0735 371 723 1 ROLLER BEARING 0,470 P
220 0735 371 723 1 ROLLER BEARING 0,470 P
230 0734 401 267 2 PISTON RING 0,003 P
 CD 1/2003 02.03.2006
sheet 20
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 172 028 00 COUPLING * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 21

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 172 028 00 COUPLING (4656 172 040)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 372 009 1 SHAFT Z=56 ZF7B C 5,300 P
020 0636 607 039 1 STUD M 10 X 16 8.8 0,013 P
030 4656 272 007 1 COUPLING 7,350 P
/030 4656 372 030 1 DISC CARRIER 3,500 P
/040 4656 272 003 1 PISTON 0,400 P
/060 0634 313 574 1 O-RING 64 X 3 ZFN 744 FPM-70-10 0,002 P
/070 0634 313 498 1 O-RING 120 X 3 ZFN 744 FPM-70-10 0,005 P
/080 4642 308 083 2 GUIDE RING 0,010 P
/090 0732 041 183 1 COMPR.SPRING 0,157 P
/100 0630 501 040 H 1 RETAINING RING 58 X 2 0,010 P
/105 0501 212 368 1 REIBLAMELLE 0,065 P
/108 0501 212 368 1 REIBLAMELLE 0,065 P
/110 0501 212 369 7 REIBLAMELLE 0,070 P
/120 0501 316 590 8 I.CLUTCH DISC 0,135 P
/130 0501 316 593 1 END SHIM 0,304 P
/140 1 SNAP RING P
0730 513 456 1 SNAP RING A=2,10 IN 0730 513 415 FEDEWW 0,026 P
0730 513 420 1 SNAP RING A=2,25 IN 0730 513 415 FEDEWW 0,030 P
0730 513 417 1 SNAP RING A=2,40 IN 0730 513 415 FEDEWW 0,026 P
0730 513 668 1 SNAP RING A=2,55 IN 0730 513 415 FEDEWW 0,030 P
0730 513 669 H 1 SNAP RING A=2,70 IN 0730 513 415 FEDEWW 0,030 P
0730 513 670 1 SNAP RING A=2,85 IN 0730 513 415 FEDEWW 0,040 P
0730 513 671 1 SNAP RING A=3,00 IN 0730 513 415 FEDEWW 0,031 P
0730 513 672 1 SNAP RING A=3,15 IN 0730 513 415 FEDEWW 0,035 P
0730 513 673 1 SNAP RING A=3,30 IN 0730 513 415 FEDEWW 0,035 P
0730 513 674 1 SNAP RING A=3,45 IN 0730 513 415 FEDEWW 0,035 P
0730 513 675 1 SNAP RING A=3,60 IN 0730 513 415 FEDEWW 0,038 P
0730 513 676 1 SNAP RING A=3,75 IN 0730 513 415 FEDEWW 0,040 P
0730 513 677 1 SNAP RING A=3,90 IN 0730 513 415 FEDEWW 0,040 P
0730 513 678 1 SNAP RING A=4,05 IN 0730 513 415 FEDEWW P
0730 513 679 1 SNAP RING A=4,20 IN 0730 513 415 FEDEWW 0,045 P
150 0635 290 079 2 RUNNING DISC 0,080 P
160 0735 368 077 2 AX.NEEDLE CAGE 0,025 P
170 0635 290 020 2 AXIAL WASHER 0,005 P
180 0735 321 410 2 NEEDLE CAGE 0,060 P
190 4656 372 026 1 IDLER Z=25 IN 4656 372 024 ZF7B 2,300 P
200 0501 316 377 1 RETAINING RING 0,015 P
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 22

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 172 028 00 COUPLING (4656 172 040)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
210 0735 371 723 1 ROLLER BEARING 0,470 P
220 0735 371 723 1 ROLLER BEARING 0,470 P
230 0734 401 267 2 PISTON RING 0,003 P
 CD 1/2003 02.03.2006
sheet 23
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 173 031 00 COUPLING * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 24

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 173 031 00 COUPLING (4656 173 048)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 373 012 1 SHAFT Z=57 RE IN 4656 373 011 ZF7 11,720 P
020 0636 607 039 1 STUD M 10 X 16 8.8 0,013 P
030 4656 272 007 1 COUPLING 7,350 P
/030 4656 372 030 1 DISC CARRIER 3,500 P
/040 4656 272 003 1 PISTON 0,400 P
/060 0634 313 574 1 O-RING 64 X 3 ZFN 744 FPM-70-10 0,002 P
/070 0634 313 498 1 O-RING 120 X 3 ZFN 744 FPM-70-10 0,005 P
/080 4642 308 083 2 GUIDE RING 0,010 P
/090 0732 041 183 1 COMPR.SPRING 0,157 P
/100 0630 501 040 H 1 RETAINING RING 58 X 2 0,010 P
/105 0501 212 368 1 REIBLAMELLE 0,065 P
/108 0501 212 368 1 REIBLAMELLE 0,065 P
/110 0501 212 369 7 REIBLAMELLE 0,070 P
/120 0501 316 590 8 I.CLUTCH DISC 0,135 P
/130 0501 316 593 1 END SHIM 0,304 P
/140 1 SNAP RING P
0730 513 456 1 SNAP RING A=2,10 IN 0730 513 415 FEDEWW 0,026 P
0730 513 420 1 SNAP RING A=2,25 IN 0730 513 415 FEDEWW 0,030 P
0730 513 417 1 SNAP RING A=2,40 IN 0730 513 415 FEDEWW 0,026 P
0730 513 668 1 SNAP RING A=2,55 IN 0730 513 415 FEDEWW 0,030 P
0730 513 669 H 1 SNAP RING A=2,70 IN 0730 513 415 FEDEWW 0,030 P
0730 513 670 1 SNAP RING A=2,85 IN 0730 513 415 FEDEWW 0,040 P
0730 513 671 1 SNAP RING A=3,00 IN 0730 513 415 FEDEWW 0,031 P
0730 513 672 1 SNAP RING A=3,15 IN 0730 513 415 FEDEWW 0,035 P
0730 513 673 1 SNAP RING A=3,30 IN 0730 513 415 FEDEWW 0,035 P
0730 513 674 1 SNAP RING A=3,45 IN 0730 513 415 FEDEWW 0,035 P
0730 513 675 1 SNAP RING A=3,60 IN 0730 513 415 FEDEWW 0,038 P
0730 513 676 1 SNAP RING A=3,75 IN 0730 513 415 FEDEWW 0,040 P
0730 513 677 1 SNAP RING A=3,90 IN 0730 513 415 FEDEWW 0,040 P
0730 513 678 1 SNAP RING A=4,05 IN 0730 513 415 FEDEWW P
0730 513 679 1 SNAP RING A=4,20 IN 0730 513 415 FEDEWW 0,045 P
150 0635 290 079 2 RUNNING DISC 0,080 P
160 0735 368 077 2 AX.NEEDLE CAGE 0,025 P
170 0635 290 020 2 AXIAL WASHER 0,005 P
180 0735 321 410 2 NEEDLE CAGE 0,060 P
190 4656 373 009 1 IDLER Z=55 K3 ZF7B C 2,960 P
210 0735 371 723 1 ROLLER BEARING 0,470 P
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 25

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 173 031 00 COUPLING (4656 173 048)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
220 0735 371 722 1 ROLLER BEARING 0,677 P
230 0734 401 267 2 PISTON RING 0,003 P
 CD 1/2003 02.03.2006
sheet 26
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 174 019 00 COUPLING * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 27

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 174 019 00 COUPLING (4656 174 038)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 374 023 1 SHAFT Z=30 IN 4656 374 011 ZF7B 8,800 P
020 0636 607 039 1 STUD M 10 X 16 8.8 0,013 P
030 4656 374 014 1 GEAR Z=61 ZF7B C 3,400 P
040 0630 501 050 1 RETAINING RING 80X2,5 0,030 P
050 0635 290 020 3 AXIAL WASHER 0,005 P
060 0735 368 077 2 AX.NEEDLE CAGE 0,025 P
070 0635 290 079 1 RUNNING DISC 0,080 P
080 0735 321 410 2 NEEDLE CAGE 0,060 P
090 4656 374 016 1 IDLER Z=40 IN 4656 374 015 ZF7B 2,000 P
100 4656 274 001 1 COUPLING P
/100 4656 374 034 1 DISC CARRIER P
/110 4656 272 003 1 PISTON 0,400 P
/130 0634 313 574 1 O-RING 64 X 3 ZFN 744 FPM-70-10 0,002 P
/140 0634 313 498 1 O-RING 120 X 3 ZFN 744 FPM-70-10 0,005 P
/150 4642 308 083 2 GUIDE RING 0,010 P
/160 0732 041 183 1 COMPR.SPRING 0,157 P
/170 0630 501 040 H 1 RETAINING RING 58 X 2 0,010 P
/175 0501 212 368 1 REIBLAMELLE 0,065 P
/179 0501 212 368 1 REIBLAMELLE 0,065 P
/181 0501 212 369 5 REIBLAMELLE 0,070 P
/190 0501 316 590 6 I.CLUTCH DISC 0,135 P
/200 0501 316 593 1 END SHIM 0,304 P
/210 1 SNAP RING P
0730 513 456 1 SNAP RING A=2,10 IN 0730 513 415 FEDEWW 0,026 P
0730 513 420 1 SNAP RING A=2,25 IN 0730 513 415 FEDEWW 0,030 P
0730 513 417 1 SNAP RING A=2,40 IN 0730 513 415 FEDEWW 0,026 P
0730 513 668 1 SNAP RING A=2,55 IN 0730 513 415 FEDEWW 0,030 P
0730 513 669 H 1 SNAP RING A=2,70 IN 0730 513 415 FEDEWW 0,030 P
0730 513 670 1 SNAP RING A=2,85 IN 0730 513 415 FEDEWW 0,040 P
0730 513 671 1 SNAP RING A=3,00 IN 0730 513 415 FEDEWW 0,031 P
0730 513 672 1 SNAP RING A=3,15 IN 0730 513 415 FEDEWW 0,035 P
0730 513 673 1 SNAP RING A=3,30 IN 0730 513 415 FEDEWW 0,035 P
0730 513 674 1 SNAP RING A=3,45 IN 0730 513 415 FEDEWW 0,035 P
0730 513 675 1 SNAP RING A=3,60 IN 0730 513 415 FEDEWW 0,038 P
0730 513 676 1 SNAP RING A=3,75 IN 0730 513 415 FEDEWW 0,040 P
0730 513 677 1 SNAP RING A=3,90 IN 0730 513 415 FEDEWW 0,040 P
0730 513 678 1 SNAP RING A=4,05 IN 0730 513 415 FEDEWW P
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 28

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 174 019 00 COUPLING (4656 174 038)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
0730 513 679 1 SNAP RING A=4,20 IN 0730 513 415 FEDEWW 0,045 P
220 0630 501 035 1 RETAINING RING 0,010 P
230 0735 371 723 1 ROLLER BEARING 0,470 P
240 0735 371 723 1 ROLLER BEARING 0,470 P
250 0734 401 267 2 PISTON RING 0,003 P
 CD 1/2003 02.03.2006
sheet 29
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 175 021 00 COUPLING * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 30

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 175 021 00 COUPLING (4656 175 035)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 375 011 1 SHAFT Z=55 KV ZF7B C 5,790 P
020 0636 607 039 1 STUD M 10 X 16 8.8 0,013 P
030 4656 375 016 1 IDLER Z=49 IN 4656 375 022 ZF7B 4,160 P
040 0735 321 408 1 NEEDLE CAGE 0,082 P
050 0750 116 380 1 BALL BEARING 0,373 P
060 0630 502 042 1 RETAINING RING 90X3 0,040 P
070 0630 501 038 H 1 RETAINING RING 55X2 0,010 P
080 4656 275 001 1 COUPLING 7,350 P
/080 4656 375 026 1 DISC CARRIER 5,100 P
/090 4657 275 006 1 PISTON 0,400 P
/110 0634 313 643 1 O-RING 75 X 3 ZFN 744 FPM-70-10 0,010 P
/120 0634 313 719 1 O-RING 142 X 3 ZFN 744 FPM-70-10 0,005 P
/130 0730 110 .37 1 WASHER P
/140 0732 042 711 1 COMPR.SPRING 0,448 P
/150 4656 37. 018 1 GUIDE RING P
/154 0501 316 380 1 SNAP RING 0,015 P
/160 0501 212 372 9 DISC 0,090 P
/164 0501 212 373 1 O.CLUTCH DISC 0,085 P
/166 0501 212 373 1 O.CLUTCH DISC 0,085 P
/170 0501 316 591 10 I.CLUTCH DISC 0,175 P
/180 0501 316 594 1 END SHIM 0,480 P
/190 1 SNAP RING P
0730 513 684 1 SNAP RING S=2,1 IN 0730 513 683 FEDE WW 0,030 P
0730 513 685 1 SNAP RING S=2,25 IN 0730 513 683 FEDEWW 0,040 P
0730 513 686 1 SNAP RING S=2,4 IN 0730 513 683 FEDE WW 0,035 P
0730 513 687 1 SNAP RING S=2,55 IN 0730 513 683 FEDEWW 0,040 P
0730 513 688 1 SNAP RING S=2,7 IN 0730 513 683 FEDE WW 0,040 P
0730 513 698 1 SNAP RING S=2,85 IN 0730 513 683 FEDEWW 0,040 P
0730 513 689 1 SNAP RING S=3,00 IN 0730 513 683 FEDEWW 0,043 P
0730 513 690 1 SNAP RING S=3,15 IN 0730 513 683 FEDEWW 0,045 P
0730 513 691 1 SNAP RING S=3,30 IN 0730 513 683 FEDEWW 0,048 P
0730 513 692 1 SNAP RING S=3,45 IN 0730 513 683 FEDEWW 0,050 P
0730 513 693 1 SNAP RING S=3,60 IN 0730 513 683 FEDEWW 0,043 P
0730 513 694 1 SNAP RING S=3,75 IN 0730 513 683 FEDEWW 0,055 P
0730 513 695 1 SNAP RING S=3,90 IN 0730 513 683 FEDEWW 0,055 P
0730 513 696 H 1 SNAP RING S=4,05 IN 0730 513 683 FEDEWW 0,059 P
0730 513 697 1 SNAP RING S=4,20 IN 0730 513 683 FEDEWW 0,061 P
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 31

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 175 021 00 COUPLING (4656 175 035)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
200 0735 371 723 1 ROLLER BEARING 0,470 P
210 0735 371 723 1 ROLLER BEARING 0,470 P
220 0734 401 267 2 PISTON RING 0,003 P
 CD 1/2003 02.03.2006
sheet 32
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 176 026 00 COUPLING * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 33

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 176 026 00 COUPLING (4656 176 041)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 376 004 1 SHAFT Z=58 LI/KR ZF7B 5,950 P
020 0636 607 039 1 STUD M 10 X 16 8.8 0,013 P
030 4656 375 016 1 IDLER Z=49 IN 4656 375 022 ZF7B 4,160 P
040 0735 321 408 1 NEEDLE CAGE 0,082 P
050 0750 116 380 1 BALL BEARING 0,373 P
060 0630 502 042 1 RETAINING RING 90X3 0,040 P
070 0630 501 038 H 1 RETAINING RING 55X2 0,010 P
080 4656 275 001 1 COUPLING 7,350 P
/080 4656 375 026 1 DISC CARRIER 5,100 P
/090 4657 275 006 1 PISTON 0,400 P
/110 0634 313 643 1 O-RING 75 X 3 ZFN 744 FPM-70-10 0,010 P
/120 0634 313 719 1 O-RING 142 X 3 ZFN 744 FPM-70-10 0,005 P
/130 0730 110 .37 1 WASHER P
/140 0732 042 711 1 COMPR.SPRING 0,448 P
/150 4656 37. 018 1 GUIDE RING P
/154 0501 316 380 1 SNAP RING 0,015 P
/160 0501 212 372 9 DISC 0,090 P
/164 0501 212 373 1 O.CLUTCH DISC 0,085 P
/166 0501 212 373 1 O.CLUTCH DISC 0,085 P
/170 0501 316 591 10 I.CLUTCH DISC 0,175 P
/180 0501 316 594 1 END SHIM 0,480 P
/190 1 SNAP RING P
0730 513 684 1 SNAP RING S=2,1 IN 0730 513 683 FEDE WW 0,030 P
0730 513 685 1 SNAP RING S=2,25 IN 0730 513 683 FEDEWW 0,040 P
0730 513 686 1 SNAP RING S=2,4 IN 0730 513 683 FEDE WW 0,035 P
0730 513 687 1 SNAP RING S=2,55 IN 0730 513 683 FEDEWW 0,040 P
0730 513 688 1 SNAP RING S=2,7 IN 0730 513 683 FEDE WW 0,040 P
0730 513 698 1 SNAP RING S=2,85 IN 0730 513 683 FEDEWW 0,040 P
0730 513 689 1 SNAP RING S=3,00 IN 0730 513 683 FEDEWW 0,043 P
0730 513 690 1 SNAP RING S=3,15 IN 0730 513 683 FEDEWW 0,045 P
0730 513 691 1 SNAP RING S=3,30 IN 0730 513 683 FEDEWW 0,048 P
0730 513 692 1 SNAP RING S=3,45 IN 0730 513 683 FEDEWW 0,050 P
0730 513 693 1 SNAP RING S=3,60 IN 0730 513 683 FEDEWW 0,043 P
0730 513 694 1 SNAP RING S=3,75 IN 0730 513 683 FEDEWW 0,055 P
0730 513 695 1 SNAP RING S=3,90 IN 0730 513 683 FEDEWW 0,055 P
0730 513 696 H 1 SNAP RING S=4,05 IN 0730 513 683 FEDEWW 0,059 P
0730 513 697 1 SNAP RING S=4,20 IN 0730 513 683 FEDEWW 0,061 P
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 34

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 176 026 00 COUPLING (4656 176 041)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
200 0735 371 723 1 ROLLER BEARING 0,470 P
210 0735 371 723 1 ROLLER BEARING 0,470 P
220 0734 401 267 2 PISTON RING 0,003 P
 CD 1/2003 02.03.2006
sheet 35
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 103 060 00 OUTPUT * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 36

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 103 060 00 OUTPUT (4656 103 008)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 303 007 1 OUTPUT SHAFT Z=56 IN 4656 303 005 ZF7B 10,670 P
020 0735 371 722 1 ROLLER BEARING 0,677 P
030 0735 371 722 1 ROLLER BEARING 0,677 P
040 0750 111 307 2 SHAFT SEAL 0,064 P
044 0634 306 328 2 O-RING 38 X 4 NBR -70-10 0,005 P
050 0730 002 713 2 WASHER IN 0730 006 923 C45 0,183 P
060 0636 015 416 4 HEXAGON SCREW M 8 X 25 10.9 A3C 0,010 P
070 0730 749 184 2 TAB WASHER IN 1313 304 043 ST1303 0,010 P
 CD 1/2003 02.03.2006
sheet 37
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 103 061 00 OUTPUT * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 38

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 103 061 00 OUTPUT (4656 103 410)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
080 4656 303 014 1 OUTPUT FLANGE ZF50 3,600 P
090 0636 011 024 8 HEXAGON SCREW K00170/00 M 12 X 50 10.9 AU 0,023 P
 CD 1/2003 02.03.2006
sheet 39
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 109 060 00 PARKING BRAKE * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 40

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 109 060 00 PARKING BRAKE (4656 109 002)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 0501 211 070 1 BRAKE K01077/97 8,800 P
/020 0501 317 036 1 PISTON 0,668 P
/030 0501 317 037 1 PRESSURE RING 0,464 P
/040 0501 317 038 1 PRESSURE PIN 0,284 P
/060 0501 317 040 2 DAUERMAGNET 0,010 P
/070 0501 317 041 2 CLEARANCE RING 0,001 P
/110 0501 317 045 6 CUP SPRING 0,110 P
/120 0501 317 046 1 O-RING 27 X 2,5 0,001 P
/150 0630 502 075 1 RETAINING RING 92X3 0,030 P
/160 0501 321 274 1 SCREW CAP K01123/03 0,385 P
/170 0501 317 049 1 O-RING 44 X 4 0,003 P
/180 0501 209 288 1 BREATHER 0,342 P
/190 0501 317 060 1 SET SCREW 0,046 P
/200 0501 317 061 1 HEXAGON NUT M 16 0,018 P
/240 0501 317 572 2 PIN K02050/98 0,232 P
/250 0501 317 573 2 SPR.COTTER PIN K02050/98 0,003 P
/260 0501 211 346 1 BR.LINING KIT K01123/03 2,000 P
/270 0501 211 347 1 SEAL KIT K01123/03 1,000 P
/010 0501 317 042 1 DUST CAP P
/020 0501 317 043 1 U-RING 45 P
/030 0501 317 044 1 U-RING 90 0,016 P
/040 0501 317 047 1 O-RING 91 X 2,5 0,001 P
100 4462 301 207 1 BRAKE DISC IN 4462 301 194 F500 8,510 P
140 0636 015 166 H 6 HEXAGON SCREW K01314/98 M 10 X 25 10.9 AU 0,025 P
150 0630 001 014 6 WASHER K01314/98 0,002 P
160 0636 115 031 H 4 CAP SCREW K02283/99 M 14 X 45 10.9 A3C 0,069 P
170 0501 316 789 1 BR.ANCHOR PLATE K01642/97 8,620 P
180 1 SCREW PLUG K00557/05 M10X1 KPL.MIT O-RING 0,005 P
/010 0636 302 053 H 1 SCREW PLUG M 10X1 ST A3C WW 0,100 P
/020 0634 303 280 1 O-RING WW 0,100 9
 CD 1/2003 02.03.2006
sheet 41
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 109 061 00 PARKING BRAKE * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 42

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 109 061 00 PARKING BRAKE (4656 109 408)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
024 4656 309 003 1 OUTPUT FLANGE K02210/99 ZF50 4,680 P
040 0636 011 024 8 HEXAGON SCREW K02210/99 M 12 X 50 10.9 AU 0,023 P
 CD 1/2003 02.03.2006
sheet 43
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 154 003 00 POWER TAKE-OFF * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 44

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 154 003 00 POWER TAKE-OFF (4656 154 005)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 354 011 1 PUMP SHAFT Z=21 ZF6 A ZF 2,235 P
020 0634 402 140 1 PISTON RING 50 X 2,5 SH P NORMAUS 0,005 P
030 0750 116 008 H 1 BALL BEARING 0,404 P
040 0630 502 040 1 RETAINING RING 85X3 0,080 P
100 4656 354 008 1 COVER PLATE IN 4656 354 007 F270 0,830 P
110 0634 313 179 1 O-RING K01463/97 104 X 3 FPM -70-10 0,004 P
114 0636 016 221 H 4 HEXAGON SCREW M 12 X 18 10.9 A3C 0,030 P
 CD 1/2003 02.03.2006
sheet 45
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 106 020 00 GEARSHIFT SYST. * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 46

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 106 020 00 GEARSHIFT SYST. (4656 106 012)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 306 136 1 GASKET 11950 0,020 P
020 4656 306 151 H 1 DUCT PLATE EN AC-ALSI8CU3KF 2,960 P
024 4656 306 110 1 GASKET 11950 0,019 P
030 4656 306 096 1 INTERM.SHEET GD-SCHALTUNG F270 0,730 P
034 4656 306 097 H 1 GASKET WG160 11950 0,019 P
040 0736 101 312 H 37 TORX SCREW M8X30 IN 0736 101 263 10.9 0,100 P
051 0636 607 054 14 STUD M 8 X 25 10.9 A3C 0,010 P
070 0637 025 005 H 14 HEXAGON NUT M 8 10 A2C 0,007 P
200 0736 101 261 H 23 TORX SCREW M6X80 IN 0736 101 258 10.9 0,024 P
780 1 SCREW PLUG 0,020 P
/010 0636 302 065 1 SCREW PLUG M 16X1,5 ST A3C WW 0,020 P
/020 0634 316 523 1 O-RING 13 X 2 FPM -70-10 WW 0,004 P
798 0732 042 761 1 COMPR.SPRING DRAHT D=1,6 FEDERS 0,009 P
799 4657 306 031 1 PISTON EN AW-6082[ALSI1MGMN] 0,015 P
 CD 1/2003 02.03.2006
sheet 47
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4657 106 021 00 GEARSHIFT SYST. * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 48

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4657 106 021 00 GEARSHIFT SYST. (4657 106 407)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
770 0501 210 966 1 SWITCH 0,075 P
 CD 1/2003 02.03.2006
sheet 49
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 159 018 21 GEARSHIFT SYST. * depending on parts list no.
 CD 1/2003 02.03.2006
sheet 50
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 159 018 22 GEARSHIFT SYST. * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 51

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 159 018 21 GEARSHIFT SYST. (4656 159 016)
4656 159 018 22 GEARSHIFT SYST. (4656 159 016)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 306 112 H 1 VALVE BLOCK IN 4656 306 111 GD-ALSI9CU 2,200 P
012 8 SCREW PLUG M10X1 KPL.MIT O-RING 0,005 P
/010 0636 302 053 H 8 SCREW PLUG M 10X1 ST A3C WW 0,100 P
/020 0634 303 280 8 O-RING WW 0,100 9
020 0730 361 070 6 ORIFICE A=0,8 IN 0730 361 120 FU27 0,001 P
030 4656 306 095 6 PISTON NACHFOLGESCHIEBER E 0,020 P
040 0732 042 538 6 COMPR.SPRING 0,005 P
050 4656 306 013 6 PISTON EN AW-ALSIMGMN T6 WW. 0,005 P
060 0732 042 539 6 COMPR.SPRING 0,007 P
070 4656 306 074 1 PISTON EN AW-ALSIMGMN T6 0,015 P
080 0732 042 631 1 COMPR.SPRING 0,015 P
090 4656 306 152 1 CONTROL PISTON EN AW-ALSIMGMN T6 WW. 0,035 P
110 0732 042 719 1 COMPR.SPRING 0,033 P
150 4656 306 158 1 GASKET S=1,0 11972 0,005 P
160 4656 306 116 1 HOUSING GD-ALSI9CU3 0,550 P
170 0736 101 257 H 18 TORX SCREW M5 IN 0736 101 256 10.9 0,005 P
180 0501 314 770 3 PRESS.REGULATOR KOMPLETT MIT O-RING 0,122 P
/010 0734 313 134 H 3 O-RING 13,5 X 2 FPM-70-10 0,001 P
190 1043 326 045 3 FIXING PLATE CK67GBK MK75 0,003 P
200 0736 101 094 H 3 CAP SCREW M5X12 IN 0736 101 053 8.8 0,003 P
210 4656 306 158 1 GASKET S=1,0 11972 0,005 P
220 4656 306 116 1 HOUSING GD-ALSI9CU3 0,550 P
230 0736 101 257 H 18 TORX SCREW M5 IN 0736 101 256 10.9 0,005 P
240 0501 314 770 3 PRESS.REGULATOR KOMPLETT MIT O-RING 0,122 P
/010 0734 313 134 H 3 O-RING 13,5 X 2 FPM-70-10 0,001 P
250 1043 326 045 3 FIXING PLATE CK67GBK MK75 0,003 P
260 0736 101 094 H 3 CAP SCREW M5X12 IN 0736 101 053 8.8 0,003 P
270 4656 206 006 1 WIRING HARNESS 0,100 P
280 4656 306 157 1 GASKET S=1,0 11972 0,005 P
290 4656 306 054 H 1 COVER AUSF.I IN 4656 306 053 GD- 0,275 P
300 0736 101 257 H 14 TORX SCREW M5 IN 0736 101 256 10.9 0,005 P
310 4656 306 157 1 GASKET S=1,0 11972 0,005 P
320 4656 306 055 H 1 COVER AUSF.II IN 4656 306 053 GD- 0,535 P
330 1058 327 026 1 RETAINING CLAMP X12CRNI 17 7 0,020 P
340 0736 101 257 H 14 TORX SCREW M5 IN 0736 101 256 10.9 0,005 P
350 4656 306 125 H 1 GASKET WG160 11950 0,011 P
360 4656 306 167 H 1 INTERM.SHEET D-TEIL ZFN410-F27 0,440 P
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 52

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 159 018 21 GEARSHIFT SYST. (4656 159 016)
4656 159 018 22 GEARSHIFT SYST. (4656 159 016)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
362 0501 316 715 6 SCREEN MASCHENW.200MY 0,001 P
370 4656 306 127 H 1 GASKET WG160 11950 0,012 P
380 4656 306 150 1 DUCT PLATE GD-ALSI9CU3 0,660 P
390 0736 101 259 18 TORX SCREW M6X25 IN 0736 101 258 10.9 0,005 P
 CD 1/2003 02.03.2006
sheet 53
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 120 002 00 PRESS.REGULATOR * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 54

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 120 002 00 PRESS.REGULATOR (4656 120 005)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 0501 211 384 1 VALVE 0,084 P
040 4656 306 077 1 PRESSURE PLATE ALMGSI0,5F13 0,006 P
050 4656 306 078 1 TAB WASHER F270 0,020 P
060 4656 306 107 1 PISTON ALSIMGMN T6 0,025 P
070 0732 042 767 1 COMPR.SPRING FEDERSTAHL 0,036 P
080 0501 213 034 1 PRESS.REL.VALVE K01932/01 0,030 P
 CD 1/2003 02.03.2006
sheet 55
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 122 001 00 PRESS.OIL PUMP * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 56

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 122 001 00 PRESS.OIL PUMP (4656 122 004)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 0501 214 562 1 GEAR PUMP K00284/04 0,007 P
/050 0501 316 582 1 RING 0,150 P
/060 0501 316 583 1 SUPPORT SHIM 0,050 P
/070 0501 316 584 H 1 NEEDLE BEARING 0,168 P
/080 0634 311 837 1 SHAFT SEAL 75 X 95 10 ZFN 132 0,045 P
/100 0501 316 586 1 SNAP RING 0,017 P
020 10 CAP SCREW K00401/98 0,053 P
/010 0636 101 120 10 CAP SCREW M 10 X 75 8.8 FE/ZN8WW 0,052 P
/020 0634 313 215 10 O-RING 9,5 X 1,6 FPM -70-10 WW 0,001 P
030 0634 313 980 1 O-RING K00179/97 182 X 3 FPM -70-10 0,008 P
 CD 1/2003 02.03.2006
sheet 57
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 137 001 00 EMCY.STEER.PUMP * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 58

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 137 001 00 EMCY.STEER.PUMP (4656 137 004)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4656 337 005 1 COVER F270 2,090 P
020 4656 337 010 1 GASKET K00072/01 11970 0,010 P
040 0636 015 225 23 HEXAGON SCREW K00519/97 M 8 X 18 8.8 A3C 0,010 P
 CD 1/2003 02.03.2006
sheet 59
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 125 002 00 IND.TRANSMITTER * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 60

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 125 002 00 IND.TRANSMITTER (4656 125 006)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 0501 209 719 3 IND.TRANSMITTER KOMPLETT MIT O-RING 0,050 P
/010 0734 313 125 3 O-RING 15 X 2 0,002 P
020 0501 317 949 1 SPEED TRANSMITT K02042/99 KOMPLETT MIT O-RING 0,040 P
/010 0634 313 728 H 1 O-RING 15,54 X 2,62 ZFN 744 ACM-70-10 0,001 P
030 0636 101 680 H 1 CAP SCREW M 8 X 16 8.8 FE/ZN8 0,010 P
044 1 SCREW PLUG 0,075 P
/010 0636 302 067 1 SCREW PLUG M 26X1,5 ST A3C WW 0,070 P
/020 0634 313 233 1 O-RING 23 X 2 FPM -70-10 WW 0,550 P
 CD 1/2003 02.03.2006
sheet 61
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4657 124 004 00 TEMP.SENSOR * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 62

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4657 124 004 00 TEMP.SENSOR (4657 124 003)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
054 1 TEMP.SENSOR K00264/02 0,090 P
/260 0501 317 260 H 1 TEMP.SENSOR WW 0,100 P
/270 0634 306 522 1 O-RING 11 X 2 NBR -70-10 WW 0,002 P
 CD 1/2003 02.03.2006
sheet 63
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 138 002 01 FILTER * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 64

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 138 002 01 FILTER (4656 138 005)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
050 0736 101 366 2 TORX SCREW K02534/01 M8X40 IN 0736 101 263 10.9 0,021 P
 CD 1/2003 02.03.2006
sheet 65
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 199 009 00 LOOSE PARTS * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 66

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 199 009 00 LOOSE PARTS (4656 199 402)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 0501 323 154 1 PRESSURE FILTER K00109/06 24.06.2006 P
010 0750 131 061 1 EXCHANGE FILTER K00109/06 1,010 P
040 0501 210 350 1 FILTER HEAD K00638/99 0,380 P
/010 0634 313 061 2 O-RING 34,2 X 3 ZFN 744 FPM-70-10 0,002 P
 CD 1/2003 02.03.2006
sheet 67
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 131 004 00 OIL DIPSTICK * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 68

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 131 004 00 OIL DIPSTICK (4656 131 003)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 4642 231 127 H 1 OIL LEVEL TUBE K02532/95 IN 4642 231 004 0,765 P
020 4657 231 006 1 OIL DIPSTICK K00224/98 KPL. IN 4657 231 005 0,100 P
022 4642 331 216 2 GASKET K02465/95 IN 4642 331 215 TS 9003 ARM 0,001 P
030 0636 015 225 2 HEXAGON SCREW K00514/97 M 8 X 18 8.8 A3C 0,010 P
040 0636 010 741 2 HEXAGON SCREW K00520/97 M 8 X 50 10.9 A3C 0,025 P
050 4644 301 014 1 COVER PLATE K02465/95 IN 4644 301 086 F270 0,012 P
 CD 1/2003 02.03.2006
sheet 69
parts list: 4656 056 018 6 WG-160 / / MISTA
figure: 4656 183 008 00 LOOSE PARTS * depending on parts list no.
 ZF-ELCAT parts list CD 1/2003 02.03.2006
sheet 70

parts list: 4656 056 018 6 WG-160 / / MISTA

figure: 4656 183 008 00 LOOSE PARTS (4656 183 021)

item part no. OCF description mod. no. mod. intr. technical information opt. customer's code no. weight suppl.plant
010 6006 035 005 1 RANGE SELECTOR VTS-3 I 6006 635 005 1,400 P
020 6029 017 060 1 CABLE CONNECT. EST-37/RL2 KL 2,000 P
050 6007 203 236 1 DISPLAY K01117/00 O. GEH. MNL (2X4POL) 0,240 P
120 6029 199 008 1 PLUG 4POL M-N-L BU 0,010 P
130 6029 199 043 1 PLUG JUN. POWER TIMER 22 POL 0,025 P
160 6009 092 152 H 1 CONTROL UNIT K00106/03 1,000 P
/020 6009 365 007 1 CONTROL UNIT EST-37A 1,500 P
/040 6009 365 002 H 1 TYPE PLATE EST-37 SOMMER GMBH/SCH 0,001 P

**** END ****
